ABB 3HNE08539-1 Servo Motor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3HNE08539-1 Servo Motor is a high-performance AC servo motor designed for use with ABB servo drives. It provides precise position, speed, and torque control, making it ideal for industrial automation, robotics, machine tools, and packaging equipment. The motor features high responsiveness, low inertia, and excellent control performance.

2. Technical Specifications

• Model: 3HNE08539-1

• Product Type: Servo Motor

• Rated Power: 0.75 kW

• Rated Voltage: 230 V AC

• Rated Current: 3.4 A

• Rated Speed: 3000 rpm

• Max Speed: 5000 rpm

• Rated Torque: 2.39 Nm

• Max Torque: 7.18 Nm

• Inertia: 0.0012 kg·m²

• Pole Pairs: 4

• Feedback Type: Incremental encoder / Resolver

• Insulation Class: F

• Protection Class: IP65

• Bearing Type: Ball bearing

• Mounting Method: Flange / Bolt mounting

• Ambient Temperature: ‑10 ℃ to +40 ℃

• Relative Humidity: 5 % to 95 % (non-condensing)

• Cooling Method: Natural ventilation / Forced air optional

• Standards: IEC 60034, UL 1004

3. Advantages and Features

1. High Precision Control
   Works with ABB servo drives to achieve precise position, speed, and torque control.

2. Fast Response
   Low inertia design and optimized control provide rapid dynamic response.

3. Reliable and Durable
   Industrial-grade design with ball bearings and high-quality materials ensures long-term stable operation.

4. Compact Design
   Small form factor suitable for space-constrained industrial applications.

5. Excellent Protection
   IP65 protection allows use in dusty or lightly splashed environments.

6. Flexible Feedback Options
   Supports encoder and resolver feedback to suit application requirements.

4. Typical Applications

• Industrial robots and automated assembly lines

• CNC machines and machining equipment

• Packaging and printing machinery

• Automated material handling systems

• High-precision motion control systems

• OEM industrial automation equipment

5. Installation and Usage Notes

1. Verify the motor’s rated voltage, power, and speed are compatible with the drive before installation.

2. Wiring must be done with power off to avoid damage to the motor or drive.

3. Avoid installation in high temperature, high humidity, or corrosive environments; if necessary, provide protection.

4. Regularly check bearings and mechanical connections to ensure smooth operation.

5. Avoid excessive impact or overloading on the motor shaft to extend service life.
