ABB 3HNA003542-001 Connector Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • 1. Product Overview

    The ABB 3HNA003542-001 is an industrial connector board used in ABB control systems, drives, and automation equipment to provide signal, power, and communication interfaces between modules. It features a compact design and high-reliability industrial-grade components, ensuring stable signal transmission, minimizing contact issues, and reducing interference. The modular design allows easy installation, replacement, and maintenance in control cabinets.

    ---

    2. Technical Specifications

    Parameter	Description
    Model	3HNA003542-001
    Type	Connector Board / Interface Board
    Interface Type	Digital Input/Output (DI/DO), Analog Input/Output (AI/AO), Power and Communication Interfaces
    Power Supply	24 V DC (as per system specification)
    Communication Interface	Supports ABB internal bus or standard industrial protocols
    Power Consumption	~2–4 W (typical)
    Mounting	Panel-mounted inside control cabinet or DIN rail
    Response Time	≤ 10 ms (digital signal)
    Operating Temperature	-20℃ to +60℃
    Protection	IP20
    Housing Material	Flame-retardant plastic
    Dimensions	120 × 80 × 25 mm (approx.)
    Standards	IEC 61131-2 / EN 61010

    ---

    3. Key Advantages & Features

    1. High-Reliability Connections

       • Industrial-grade design and quality terminals ensure long-term stable signal transmission.

    2. Multi-Functional Interfaces

       • Supports digital, analog, power, and communication interfaces for diverse industrial applications.

    3. Modular Design

       • Easy installation, maintenance, and replacement to improve system maintainability.

    4. Strong Interference Immunity

       • Optimized circuitry and terminal design reduce noise in industrial environments.

    5. Compact Size

       • Saves control cabinet space and simplifies wiring layout.

    ---

    4. Typical Applications

    • Industrial automation system connection interfaces

    • PLC/DCS module signal, power, and communication connections

    • Drive, motor, and sensor system interfacing

    • Automated production line and data acquisition systems

    • Packaging, printing, textile machinery, and robotic control systems

    ---

    5. Usage Precautions

    • Installation: Must be installed by qualified personnel; ensure board is securely mounted and terminals are properly connected.

    • Power Supply: Input voltage must meet system specifications to prevent overvoltage or undervoltage.

    • Signal Matching: Connected input/output signal types must be compatible with control modules.

    • Environmental Conditions: Avoid high temperature, humidity, dust, and corrosive gases.

    • Regular Inspection: Check connection status and terminal tightness to ensure reliable signal transmission.

  •
  •

The structure and details of the product：
