ABB 3HEA505956/00 Servo Motor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

•

• 1. Product Overview

  The ABB 3HEA505956/00 is a high-performance servo motor designed for precise position, speed, and torque control in industrial automation systems. It features high-efficiency permanent magnet synchronous technology, providing fast response, high accuracy, and reliability. The modular design allows seamless integration with ABB drives and controllers, suitable for robots, machine tools, automated production lines, and precision control equipment.

  ---

  2. Technical Specifications

  Parameter	Description
  Model	3HEA505956/00
  Type	Permanent Magnet Synchronous Servo Motor
  Rated Power	1.0 kW
  Rated Voltage	230 V AC / 400 V AC (matched with drive)
  Rated Current	4.5 A
  Rated Speed	3000 rpm
  Peak Torque	4.8 Nm
  Continuous Torque	3.2 Nm
  Feedback Device	Incremental or absolute encoder (optional)
  Protection	IP65 (standard)
  Insulation Class	F
  Shaft Size	φ19 mm × 40 mm
  Mounting	Flange or foot mounting
  Operating Temperature	-20℃ to +50℃
  Brake	Optional electromagnetic brake
  Standards	IEC 60034 / EN 60034

  ---

  3. Key Advantages & Features

  1. High-Precision Control

     • High-resolution encoder and low mechanical backlash ensure accurate position, speed, and torque control.

  2. Fast Response

     • Optimized servo drive and motor cooperation for short response time, suitable for high-dynamic control.

  3. High Efficiency and Reliability

     • Permanent magnet synchronous technology reduces energy loss and supports continuous operation.

  4. Modular Design

     • Easy integration with ABB drives and controllers; convenient installation and maintenance.

  5. Versatile Configuration

     • Optional brakes, different encoders, and shaft sizes meet various industrial application needs.

  ---

  4. Typical Applications

  • Industrial robots and collaborative robots

  • CNC machine tools and automation equipment

  • Automated production and assembly lines

  • Packaging machines, printing machines, and textile equipment

  • Precision motion control and servo drive systems

  ---

  5. Usage Precautions

  • Installation: Ensure flange or foot mounting is secure and motor shaft properly aligned.

  • Power Matching: Motor rated voltage must match drive output voltage to prevent motor or drive damage.

  • Cooling Requirements: Ensure proper ventilation to avoid overheating.

  • Maintenance: Periodically check encoder, wiring, and bearings for precise operation.

  • Environmental Conditions: Avoid humidity, dust, corrosive gases, and excessive vibration.

•

The structure and details of the product：
