ABB 3HAC9710-1 Robotic Heat Exchanger Unit
Item NO.:
3HAC9710-1Payment:
T/TPrice:
$1200Product Origin:
ChinaColor:
NEWLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
The ABB 3HAC9710-1 Robotic Heat Exchanger Unit is a thermal management device designed for industrial robot drive systems. It efficiently dissipates heat and lowers the operating temperature of servo drives and motors, enhancing system stability and lifespan. The modular design allows direct installation in robot control cabinets or next to drive units, suitable for a variety of industrial automation environments.
| Parameter | Specification |
|---|---|
| Model | 3HAC9710-1 |
| Type | Robotic Heat Exchanger Unit |
| Cooling Method | Air-cooled or liquid-cooled (depending on version) |
| Compatible Devices | ABB industrial robot servo drives and servo motors |
| Thermal Power | Typically 1.5–3 kW (depending on version and environment) |
| Input Power | 24 V DC or 230 V AC (system-dependent) |
| Flow Requirement | For liquid-cooled version, pump and circulation system required, flow ~1–5 L/min |
| Operating Temperature | 0–50℃ (ambient) |
| Protection Rating | IP20–IP54 (depending on installation and version) |
| Material | High-temperature aluminum alloy and thermally conductive materials |
| Dimensions | Approx. 200 mm × 150 mm × 120 mm |
| Weight | Approx. 2.5 kg |
| Installation | Modular mounting, can be installed in control cabinet or next to drive unit |
Advantages
Efficient cooling: Significantly reduces servo drive and motor temperature, improving system reliability.
Extends equipment lifespan: Prevents overheating and component aging or failure.
Strong compatibility: Suitable for ABB industrial robot drive systems.
Features
Modular design: Easy installation, maintenance, and replacement or upgrade.
Multiple cooling options: Supports air-cooled or liquid-cooled methods for various industrial environments.
Industrial-grade durability: Resistant to high temperature, dust, and vibration.
Energy-efficient: Optimized heat exchange reduces additional power consumption.
Cooling of ABB industrial robot drive systems.
Automated production lines and robot assembly lines.
Temperature management of servo drives and motors.
Heat dissipation for long-term operation of robots in high-temperature environments.
High-dynamic load industrial robots and precision machining robots.
Confirm the cooling method (air or liquid) and interface compatibility before installation.
Ensure proper ventilation around the unit to avoid heat accumulation.
Liquid-cooled version requires a circulation pump and coolant, maintaining proper level and flow.
Regularly check heat sinks, fans, and coolant lines for blockage or leakage.
Monitor device temperature during high-temperature or continuous operation and stop the system when necessary.
Ensure secure wiring and mounting to prevent damage due to vibration.
Installation, commissioning, and maintenance should be performed by trained personnel.
