ABB 3HAC 14506-1 Serial Measurement Unit

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3HAC 14506‑1 Serial Measurement Unit is an industrial serial measurement module designed for real‑time data acquisition and transmission. It is typically used in automation control systems, robotics, and precision industrial equipment as a core component for processing sensor or encoder signals. The unit supports high‑speed serial communication and reliable data measurement mechanisms, seamlessly integrating with main controllers or higher‑level systems to ensure accurate and stable data feedback and control.FanucWorld

2. Technical Specifications

Electrical & Performance Specifications

• Model: 3HAC 14506‑1

• Type: Serial Measurement Unit

• Function: Processing sensor/encoder or digital/analog signals for measurement and feedback

• Communication Interface: Serial interfaces (e.g., RS‑485 / RS‑232 or proprietary field bus depending on system)

• Data Rate: High‑speed data exchange (protocol dependent)

• Measurement Accuracy: Designed for high precision and low measurement error

• Supply Voltage: System dependent (commonly 24 V DC in automation systems)

• Protection Features: Overcurrent, short‑circuit, and signal anomaly protection

Environmental & Mechanical Specifications

• Operating Temperature: 0 °C … +55 °C

• Storage Temperature: –20 °C … +70 °C

• Protection Rating: Typically IP20 for control cabinet installation

• Mounting: Plug‑in or rack/module chassis mount

• Approx. Size/Weight: Standard industrial module footprint, approx. 0.2–0.5 kg

This unit often serves as a measurement and feedback component within robotics and automation control loops. FanucWorld

3. Advantages & Key Features

1. High‑precision measurement — Ensures accurate data acquisition for control feedback.

2. Reliable serial communication — High‑speed, stable serial communication with controllers.

3. Wide compatibility — Integrates with ABB controllers, PLCs, and robotic systems.

4. Modular design — Easy to install, replace, and integrate in modular automation systems.

5. Industrial reliability — Designed for robust operation in standard industrial conditions.

6. Versatile use — Suitable for encoder/sensor feedback or other measurement signal tasks.

4. Application Areas

• Industrial automation measurement and feedback

• Robotic control systems requiring precise data acquisition

• PLC/DCS signal measurement and interface modules

• Encoder or sensor signal conditioning for feedback control

• Production line monitoring and process control

• Position, speed, or status signal measurement applications

5. Precautions

1. Match power supply requirements to prevent damage and ensure correct operation.

2. Ensure correct wiring of serial and measurement interfaces to avoid data errors.

3. Avoid harsh environmental conditions such as excessive humidity or corrosive atmospheres.

4. Use ESD protection when handling the module to prevent electrostatic damage.

5. Confirm compatibility with communication protocols and controller interfaces.

6. Perform regular maintenance checks on connections and communication status for stability.
