ABB 3BSE069055R1 16-channel relay output module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB 3BSE069055R1 16-Channel Relay Output Module is a digital output module designed for ABB Distributed Control Systems (DCS) and industrial automation systems. This module features 16 relay output channels and is commonly used for controlling the on/off operations of external devices. It is widely applied in process control, automation systems, and safety systems, offering electrical isolation between low-voltage control signals and high-power load devices, ensuring safety and reliability.

  ---

  2. Main Technical Parameters (Typical)

  Output Channels

  • Number of channels: 16 relay output channels

  • Relay type: Normally open (NO) relay

  Rated Data

  • Output voltage: 240 V AC / 30 V DC (depending on load type)

  • Maximum output current: 8 A per channel

  • Rated power: 2000 VA (AC load), 240 W (DC load)

  Electrical Characteristics

  • Output signal: Dry contact output (relay contacts)

  • Relay switching time: Approx. 10 ms

  • Contact durability: ≥ 10^7 operations

  • Electrical isolation: Supports isolation between input and output

  • Built-in reverse current protection for inductive loads

  Diagnostic Features

  • Channel status indication (LED display)

  • Module self-diagnosis

  • Relay fault alarm and abnormality detection

  System Interface

  • Direct compatibility with ABB controllers and I/O buses

  • Hot swap capability depending on system configuration

  Mechanical and Installation

  • Modular design with plug-in installation

  • Mounted on standard DIN rail or panel

  • Compact design to save space

  Operating Environment

  • Industrial-grade operating temperature range: -20°C to +60°C

  • Relative humidity: 5% to 95% (non-condensing)

  • Suitable for continuous operation

  ---

  3. Advantages and Features

  • High load control capacity: Each relay channel can handle up to 8 A, suitable for various industrial loads

  • Electrical isolation design: Provides electrical isolation between outputs and control systems, enhancing safety

  • Comprehensive diagnostic features: Real-time fault detection with LED and alarm indicators

  • Modular structure: Easy installation, maintenance, and replacement, with hot swap support

  • Long-lasting relays: Durable relays with a long service life for stable long-term operation

  ---

  4. Typical Applications

  • Industrial automation control systems

  • Power and energy distribution control

  • Distribution system and protection control

  • Water treatment and environmental monitoring

  • Safety and alarm systems

  • Remote equipment control and switching operations

  ---

  5. Application Notes

  • Verify the relay output voltage matches the load specifications to avoid overloading

  • Ensure correct wiring and that each output channel’s load is within rated limits

  • For inductive loads, ensure reverse current protection devices are installed

  • Ensure electrical isolation between the module and the system during installation to prevent faults

  • Regularly check relay contact wear to maintain reliable long-term operation

•
•
