ABB 3BSE025255R1 CI820V1 analog board connection unit

ABB 3BSE025255R1 CI820V1 Analog Board Connection Unit

Product Overview

The ABB 3BSE025255R1 CI820V1 Analog Board Connection Unit is a high-performance module designed to facilitate the transmission of analog input and output signals in ABB automation control systems. This module provides reliable signal interfaces and supports various analog signal types, including current, voltage, and temperature sensors (such as RTD and thermocouple). The CI820V1 efficiently converts these analog signals into digital signals or vice versa, for processing and monitoring within the system. It plays a vital role in industrial automation, process control, and equipment monitoring, ensuring high-precision and reliable data transmission.

Technical Specifications

• Model: 3BSE025255R1 CI820V1

• Type: Analog Board Connection Unit

• Signal Types: Supports voltage, current signals for input/output, and temperature sensor signals (RTD, thermocouple)

• Input/Output Channels: 8 channels (configurable for input or output)

• Signal Range:

  • Current Input/Output: 4-20mA

  • Voltage Input/Output: 0-10V

  • Temperature Input: Supports RTD (e.g., Pt100, Pt1000) and thermocouple (e.g., K, J, T, etc.)

• Signal Processing Precision: 16-bit resolution

• Input/Output Accuracy: ±0.1% (maximum)

• Communication Interface: Compatible with ABB 800xA automation systems

• Power Supply: 24V DC (typical)

• Operating Temperature Range: -5°C to 60°C

• Dimensions: 160mm x 150mm x 55mm

• Weight: 0.5 kg

• Mounting: DIN rail or panel mounting

• Redundancy Support: Supports redundancy configurations for enhanced reliability

Advantages & Features

1. Multiple Signal Support: Supports voltage, current, and temperature signals for input/output, suitable for a wide range of industrial applications.

2. High Precision Signal Processing: With 16-bit resolution, this module ensures precise analog signal handling, meeting the high-precision control and monitoring needs of industrial automation systems.

3. Reliability and Stability: Strong electromagnetic interference resistance, ensuring stable performance in demanding industrial environments without signal disruptions.

4. Redundancy Support: Supports redundancy configurations, allowing automatic switching to backup modules in case of failure, ensuring uninterrupted operation.

5. Modular Design: Seamlessly integrates with ABB 800xA automation systems, supporting hot-swapping for quick replacements and maintenance, minimizing downtime.

6. Convenient Installation & Configuration: Offers flexible installation options (DIN rail or panel) and easy configuration, enabling quick setup of input/output channels.

Application Fields

• Industrial Automation Control Systems: Widely used in automated production lines and control systems for precise signal conversion and transmission, ensuring accurate system control and monitoring.

• Process Control Systems: In industries like petrochemical, food processing, and power, the module provides high-precision analog signal input/output for stable and safe production processes.

• Equipment Monitoring Systems: Commonly used in equipment monitoring systems for real-time collection of temperature, current, voltage, etc., for fault diagnostics and operational monitoring.

• Energy Management Systems: In the energy and power sectors, the CI820V1 module is used for power monitoring, temperature control, and other key data collection, ensuring efficient power system operation.

Precautions

1. Installation Environment: Ensure the module operates within the recommended temperature range of -5°C to 60°C. Avoid exposing it to extreme temperatures.

2. Power Supply Stability: Use a stable 24V DC power supply to prevent power fluctuations from damaging the module.

3. Wiring Requirements: Follow the wiring diagram carefully to connect the signal lines correctly and avoid malfunction or incorrect signal processing.

4. Regular Checks & Calibration: Perform regular checks and calibration to maintain the module’s accuracy and stability.

5. Avoid Overload: Ensure that input and output signals remain within the module's allowed range to prevent damage from overloading.

6. ​The structure and details of the product：
7.
