ABB 3BSC950130R1 Communication Module

• • • • • • • • • • • ABB 3BSE018283R1 Communication Module (CI854 / CI854A – PROFIBUS / AC 800M System Communication Interface)







                      ---

                      Product Description

                      The ABB 3BSE018283R1 is an AC 800M / S800 system communication interface module, commonly associated with the CI854 / CI854A PROFIBUS DP interface family (exact suffix depends on hardware revision).

                      It is used in ABB 800xA Distributed Control System (DCS) environments to enable fieldbus communication between AC 800M controllers and remote I/O or third-party devices.

                      ---

                      Key Specifications

                      • Brand: ABB
                      • Part Number: 3BSE018283R1
                      • Module Type: Communication interface module
                      • System: AC 800M / 800xA / S800 I/O
                      • Protocol: PROFIBUS DP (typical for CI854A family)
                      • Function: Fieldbus communication gateway
                      • Mounting: DIN rail / rack system
                      • Redundancy: Supported in redundant system architecture
                      • Diagnostics: Built-in communication status & fault monitoring

                      ---

                      What it actually does

                      This module is used to:

                      • Connect AC 800M controller to PROFIBUS DP network
                      • Communicate with distributed S800 I/O stations
                      • Interface with drives, sensors, and third-party PLC systems
                      • Provide real-time deterministic fieldbus communication
                      • Support redundant industrial network designs



                      ---

                      System Role (Simple)

                      AC 800M controller
                      → 3BSE018283R1 communication module (this unit)
                      → PROFIBUS DP network
                      → S800 I/O / drives / field devices

                      ---

                      Key Features

                      • High-speed PROFIBUS DP communication
                      • Designed for ABB AC 800M / 800xA DCS systems
                      • Supports redundant communication architecture
                      • Real-time deterministic industrial networking
                      • Integrated diagnostics and fault detection
                      • Hot-swap / modular system design (system dependent)

                      ---

                      Typical Applications

                      • Power plants
                      • Oil & gas process control systems
                      • Chemical industry automation
                      • ABB 800xA distributed control systems
                      • Industrial process monitoring systems
                      • Large-scale factory automation networks

                      ---

                      Advantages

                      • Stable and deterministic fieldbus communication
                      • Seamless integration with ABB S800 I/O systems
                      • Supports redundant high-availability systems
                      • Industrial-grade reliability for mission-critical plants
                      • Easy integration into AC 800M architecture

                      ---

                      Important Notes

                      • Not PLC CPU ❌
                      • Not I/O module ❌
                      • Not power supply ❌
                      • It is a fieldbus communication interface module

                      ---

                      Precautions

                      • Must match correct AC 800M / 800xA system configuration
                      • PROFIBUS network must be correctly terminated
                      • Incorrect addressing can cause communication loss
                      • Requires ABB engineering tools for configuration
                      • Not interchangeable with Ethernet modules (different architecture)

The structure and details of the product：
