ABB 3BHL000389P0104 medium voltage AC drive

Product Overview:

The ABB 3BHL000389P0104 Medium Voltage AC Drive is a high-performance power control device in ABB industrial automation and power drive systems, designed for precise speed control and energy management of high-power motors. It uses advanced ABB power electronics, IGBT modules, and digital control algorithms to achieve high efficiency, low loss, and stable motor control.

Widely used in mining, petrochemical, power, steel, and water treatment industries, it provides energy-efficient, precise, and reliable motor drive solutions.

Technical Specifications:

• Model: 3BHL000389P0104

• Brand: ABB

• Type: Medium Voltage AC Drive

• Rated Power Range: 500 kW – 10 MW (system dependent)

• Rated Voltage: 3.3 kV / 6.6 kV / 11 kV (customizable)

• Rated Frequency: 50 / 60 Hz

• Input Power Type: Three-phase medium voltage AC

• Output Frequency Range: 0 – 120 Hz (adjustable)

• Control Modes: V/f control, vector control (sensorless or sensor-based)

• Switching Frequency: 2–4 kHz (adjustable)

• Protection Functions: Overcurrent, overvoltage, undervoltage, overheating, short circuit, ground fault

• Operating Temperature: -20°C to +50°C

• Storage Temperature: -40°C to +70°C

• Humidity: 5%–95% (non-condensing)

• Communication Interfaces: Profibus, Modbus, EtherNet/IP, PROFINET (optional)

• Mounting: Indoor cabinet, modular design

• Cooling Method: Air-cooled or water-cooled (power dependent)

• Compatible Systems: ABB motors and industrial automation platforms

Features and Advantages:

1. High-Performance Motor Control: Supports precise vector control and soft start to improve motor efficiency and lifespan.

2. Energy Optimization: Efficient power electronics and regenerative capability reduce operational costs.

3. High Reliability: Industrial-grade IGBT modules and digital control algorithms ensure long-term stable operation.

4. Modular Design: Plug-in unit structure simplifies installation, maintenance, and upgrades.

5. Multi-Protocol Compatibility: Supports multiple industrial communication protocols for flexible integration.

6. Intelligent Monitoring and Diagnostics: Built-in self-diagnosis and remote monitoring enhance maintenance efficiency.

7. Strong Environmental Adaptability: Operates reliably in high temperature, high humidity, and dusty environments.

Applications:

• Large industrial motor drive systems

• Mining hoists and crushers

• Petrochemical pumps, compressors, and fans

• Steel rolling mills, continuous casting machines, and steelmaking equipment

• Water treatment and pumping stations

• Power plants and energy management systems

• Ship propulsion and port cranes

• Rail traction and electric drive systems

Precautions:

1. Disconnect both main and control power before installation or maintenance to prevent electric shock or equipment damage.

2. Ensure the cooling system is functioning properly to prevent overheating of IGBT modules.

3. Avoid prolonged operation in high humidity, dusty, or corrosive environments; use protective measures if necessary.

4. Use anti-static protection during operation or maintenance to prevent damage to electronic components.

5. Regularly check drive status, operating temperature, and alarms to ensure system safety.

6. Use ABB-certified accessories and cables to ensure system compatibility and safety.
