ABB 3BHL000359P0001 Filter Capacitor Control Board Module

Product Overview

Model Code Explanation

• 3BHL: ABB power electronic auxiliary circuit board series for large power drives/converters
• 000359: Core hardware design number for filter capacitor board assembly
• P0001: Specific hardware configuration variant with fixed capacitor capacity and wiring terminal layout

Core Electrical Specifications

Filter Capacitor Parameters

• Internal capacitor group: 3 × 80μF high-voltage film capacitors, rated withstand voltage 3.3kV DC
• DC bus operating range: 0–3000 VDC
• Ripple current handling capacity: Designed for high-frequency PWM ripple of medium voltage converters
• Discharge resistance integrated: Built-in passive bleeder resistors for safe bus discharge after power cut-off

Sampling & Signal Circuit

• Voltage divider sampling circuit: Scales high DC bus voltage into low-voltage analog signals for main control board AD sampling
• Isolation grade: 2500 VDC isolation between high-voltage bus circuit and low-voltage signal loop
• Signal output interface: Standard flat cable connector for connection to main control CPU board
• Temperature monitoring thermistor: On-board NTC sensor detects capacitor operating temperature for overheat protection logic

Power Consumption & Power Supply

• Auxiliary control power: 24 VDC ±10% supplied from drive internal auxiliary power
• Standby power loss: ≤8 W; Full-load operating power loss ≤16 W

Mechanical & Environmental Data

• Mounting method: Fixed bolt installation inside power drive cabinet, adjacent to thyristor power stack
• Overall dimensions (L×W×H): 210 × 115 × 42 mm
• Net weight: 0.42 kg
• PCB protection: Conformal coated circuit board to resist dust, moisture and oil mist in industrial power rooms
• Operating temperature: -20 °C ~ +60 °C; Storage temperature: -40 °C ~ +85 °C
• Humidity: 5%–95% non-condensing
• Vibration compliance: IEC 60068-2-6 industrial vibration test standard
• Protection rating: IP00 internal cabinet component, must be installed inside sealed drive cubicle

Compatibility

1. ACS600 series cabinet-type medium voltage AC variable frequency drives
2. Industrial DC power rectifier & regenerative converter units
3. Thyristor-based active front-end (AFE) power supply modules
4. Large mining, metallurgy rolling mill main drive power cabinets

Main Functions

1. DC Bus High-Frequency Ripple Filtering



   Three built-in high-voltage capacitors absorb PWM switching ripple current on the DC link bus, stabilize bus voltage fluctuation, reduce harmonic distortion, and protect main power thyristor modules from voltage spike impact during drive switching operations.
2. High-Voltage Bus Voltage Sampling Feedback



   Precision resistor voltage divider circuit converts 3kV-level DC bus voltage into low-voltage analog signals and transmits them to the main control board. The CPU relies on this signal to implement overvoltage, undervoltage protection and voltage closed-loop regulation logic.
3. Safe Passive Discharge of DC Bus



   Integrated bleeder resistors slowly release residual high-voltage energy stored in bus capacitors after equipment shutdown, eliminating electric shock hazards during maintenance and avoiding damage to power components caused by residual voltage impact.
4. Capacitor Overheat Temperature Monitoring



   On-board temperature sensor tracks the operating temperature of filter capacitors. When overheating occurs due to aging or overload, the board sends fault signals to the main controller to trigger drive trip and alarm output, preventing capacitor bulging or explosion failures.
5. Isolation Signal Transmission Between High-Voltage and Low-Voltage Loops



   Reinforced isolation design separates high-voltage DC power loop and low-voltage control signal circuit, avoiding high-voltage breakdown and interference that cause main control board misoperation or burnout.
6. Standardized Replacement Spare Assembly



   Integrated combination of capacitors, sampling circuits, temperature detection and wiring terminals as one complete board. During on-site maintenance, the whole board can be directly replaced without separate matching of discrete capacitors and sampling components, greatly shortening equipment downtime.
