ABB 3BHE035301R0001 UNITROL1010 excitation controller

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 3BHE035301R0001 UNITROL 1010 Excitation Controller Product Details

Product Overview:

The ABB UNITROL 1010 is a high-performance Automatic Excitation Controller (AEC) designed for precise excitation regulation of synchronous generators. It provides accurate voltage and power factor control, ensuring the generator operates stably and efficiently under various conditions. The UNITROL 1010 controller is highly adjustable and flexible, making it suitable for a wide range of generator and power system applications.

Detailed Specifications:

• Input Voltage Range: AC 100V to 240V

• Output Voltage: 0 to 300V DC (depending on excitation system configuration)

• Control Accuracy: ±0.5% Voltage Stability

• Control Method: Automatic Adjustment

• Power Factor Control: Supported

• Input Frequency Range: 45 Hz to 65 Hz

• Control Algorithm: PID control algorithm

• Operating Temperature Range: -10°C to 60°C

• Communication Interface: RS232, RS485 (optional)

• Dimensions: 483mm x 250mm x 100mm

• Weight: Approx. 3.5kg

• Protection Rating: IP20

• Certifications: CE, UL, RoHS certified

Product Advantages and Features:

1. Precise Voltage Control:

   • The UNITROL 1010 provides excellent voltage control accuracy, maintaining the generator’s voltage within the set range and ensuring stable power supply.

2. Efficient Power Factor Control:

   • Supports dynamic power factor adjustment, maintaining stability even with fluctuating loads, which enhances grid stability and efficiency.

3. Flexible Control Modes:

   • Supports multiple control modes, including voltage control, power factor control, and mixed control, allowing adjustments based on various operational conditions.

4. Integrated Design:

   • Offers an integrated excitation control system that consolidates multiple functions into a single control unit, simplifying the equipment structure and reducing system costs.

5. Stable Performance:

   • Built-in advanced PID control algorithms provide fast response and stable dynamic performance, ensuring reliability under various load conditions.

6. Remote Monitoring and Diagnostics:

   • Equipped with RS232 and RS485 communication interfaces for remote monitoring and fault diagnostics, simplifying system maintenance and management.

7. Robust Protection Features:

   • Includes multiple protection mechanisms, such as overvoltage, overcurrent, and short circuit protection, ensuring the safety of the equipment and system.

8. Easy Installation and Configuration:

   • Standardized installation interfaces simplify the setup process. The user-friendly interface allows for easy parameter configuration and adjustment.

Application Areas:

1. Power Plants:

   • Used in the excitation control of synchronous generators, ensuring stable voltage output and improved power generation efficiency across thermal, hydro, and wind power plants.

2. Power Systems:

   • Effectively regulates the output power and voltage of generators, providing high-quality power to the grid.

3. Marine and Offshore Platforms:

   • Used in excitation control for ships and offshore oil platforms, ensuring stable equipment operation and reliable power supply.

4. Industrial Applications:

   • Applied in industrial automation for excitation regulation in motor drive systems and power conversion equipment, ensuring stable performance.

5. Backup Power Systems:

   • In critical facilities requiring stable power supply, UNITROL 1010 is part of backup power systems, quickly restoring power during outages.

Notes:

1. Proper Grounding:

   • Ensure proper grounding as per the installation manual to guarantee the safe operation of the system.

2. Environmental Conditions:

   • Ensure the installation environment temperature remains between -10°C and 60°C, and avoid humid, dusty, or corrosive environments.

3. Regular Inspection and Maintenance:

   • Periodically check the system’s operational status, particularly control parameters and protection functions, to ensure optimal performance.

4. Electrical Connections:

   • Ensure all electrical connections are correctly made, especially for input voltage, output voltage, and load connections, to avoid wiring errors.

5. Avoid Overloading:

   • Avoid operating the system beyond its rated load for prolonged periods, as this may cause equipment overload and damage.

The structure and details of the product：

Please make an inquiry for more models
