ABB 3BHE031734R3203 Industrial Touch Panel

1. Product Overview

The ABB 3BHE031734R3203 Industrial Touch Panel is an HMI device designed for industrial automation systems, enabling operators to monitor, control, and adjust system parameters. It provides intuitive touch operation, graphical display, and multitasking capabilities. The panel can integrate with PLCs, DCS, robot controllers, and other automation devices, delivering reliable and stable performance in industrial environments.

2. Technical Specifications

• Model: 3BHE031734R3203

• Type: Industrial Touch Panel

• Display Size: 12.1-inch TFT LCD

• Resolution: 1024 × 768 pixels

• Touch Type: Resistive or capacitive touch (optional)

• Processor: ARM or x86 industrial-grade processor

• Memory: 512 MB – 2 GB (depending on model)

• Storage: 4–16 GB flash, expandable via SD card

• Interfaces: Ethernet, USB, RS232/RS485, CAN (optional)

• Operating System: Windows CE / Windows Embedded / Linux (depending on model)

• Operating Temperature: 0°C to +50°C

• Storage Temperature: -20°C to +60°C

• Protection Rating: IP65 (front panel)

• Power Supply: 24 V DC

• Mounting: Panel mount or wall mount

• Dimensions (W×H×D): ~320 × 240 × 70 mm

• Weight: ~3.2 kg

3. Advantages and Features

• Intuitive touch operation: Supports single-point or multi-point touch, with responsive and easy-to-use interface.

• Industrial-grade reliability: Suitable for high temperature, vibration, dust, and humidity environments.

• Rich interfaces and communication: Supports Ethernet, USB, RS232/RS485, CAN, and can connect to PLCs, DCS, robots, and other devices.

• Graphical interface display: Supports graphical interfaces, alarm display, trend curves, and operation logs for efficient control.

• Expandable storage and software support: SD card expansion and support for industrial HMI software or custom applications.

4. Typical Applications

• Industrial automation production line monitoring and operation

• Robot control and monitoring

• Process control systems (PLC / DCS)

• Water treatment, power, chemical, and manufacturing industries

• Device parameter setting, alarm management, and operation logging

5. Installation & Usage Notes

• Ensure power supply is 24 V DC before installation and meets specifications.

• Keep front panel clean and avoid liquid or dust ingress.

• Do not operate outside rated temperature and humidity range.

• Regularly check communication interfaces and power connections to ensure stable operation.

• Install according to protection rating requirements to maintain IP65 performance on the front panel.
