ABB 3BHE014070R0101 communication module

Product Overview:

The ABB 3BHE014070R0101 Communication Module is a key communication component in ABB industrial automation and drive systems. It enables data transfer, signal exchange, and network connectivity. Designed with industrial-grade reliability, it supports multiple industrial communication protocols and ensures stable operation in harsh industrial environments.

This module is widely used in ABB Symphony Plus, Bailey INFI 90, ACS drives, and turbine control systems, serving as a core component for system interconnectivity and remote monitoring.

Technical Specifications:

• Model: 3BHE014070R0101

• Brand: ABB

• Type: Communication Module

• Main Function: Data transfer, signal exchange, system interconnection, remote monitoring

• Communication Interfaces: RS-485 / RS-232 / Ethernet / Profibus / Modbus (depending on system)

• Protocol Support: ABB industrial standard protocols and common fieldbus protocols

• Data Transmission Rate: 9.6 kbps – 1 Gbps (depending on interface)

• Input Voltage: 24 V DC (typical)

• Power Consumption: ≤ 10 W

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -25°C to +70°C

• Humidity: 10%–90% (non-condensing)

• Mounting: Modular rack or DIN rail

• Status Indicators: LED indicators for operation and communication status

• Compatible Systems: ABB Symphony Plus, Bailey INFI 90, ACS drives, and industrial automation control systems

Features and Advantages:

1. High Reliability Communication: Industrial-grade components ensure long-term stable operation.

2. Multi-Protocol Support: Flexible integration with various industrial communication protocols.

3. High-Speed Data Transfer: Provides stable and fast data exchange.

4. Modular Design: Plug-in structure allows easy installation, maintenance, and replacement.

5. Strong EMI Protection: Excellent electromagnetic compatibility ensures signal stability.

6. Visual Status Indicators: LED indicators enable real-time monitoring of communication status.

7. Wide Compatibility: Seamlessly integrates with multiple ABB control and drive systems.

Applications:

• Data communication in industrial automation systems

• Drive and VFD network communication

• Power and energy automation systems

• Petrochemical and refinery process monitoring

• Steel and metallurgy production automation

• Water treatment and environmental control

• Pulp and paper automation

• Turbine and large industrial equipment control systems

Precautions:

1. Disconnect power before installation or maintenance to avoid electric shock or equipment damage.

2. Ensure proper and secure wiring to prevent communication interruptions or signal loss.

3. Avoid prolonged operation in high humidity, dusty, or high EMI environments.

4. Use anti-static protection when handling or replacing the module.

5. Regularly check LED indicators and communication status to ensure normal operation.

6. Use ABB-certified communication cables and accessories for system compatibility and stability.
