ABB 3BHB040969R0001 Touch Panel

1. Product Overview

The ABB 3BHB040969R0001 is an industrial touch panel designed for human-machine interface (HMI) operations in inverters, PLCs, control systems, and industrial automation equipment.
It provides graphical operation, real-time data display, parameter settings, alarm display, trend monitoring, and data logging, improving operational efficiency and equipment usability.

2. Technical Specifications

• Model: 3BHB040969R0001

• Type: Touch Panel / HMI

• Display: Color TFT LCD

• Screen Size: Approx. 7 inches (widescreen)

• Resolution: 800 × 480 pixels

• Touch Type: Capacitive touch

• Communication Interfaces: RS485, Ethernet, CANopen (depending on configuration)

• Supported Protocols: MODBUS, CANopen, ABB inverter communication protocol

• Operating Temperature: 0 ℃ to +50 ℃

• Storage Temperature: -20 ℃ to +60 ℃

• Protection Rating: Front panel IP65 (dust and water resistant)

• Mounting: Panel-mounted

• Power Supply: 24 V DC

• Dimensions (approx.): 200 mm × 140 mm × 35 mm

• Weight (approx.): 1.2 kg

3. Key Advantages & Features

1. Intuitive Operation: Color touch screen with graphical interface for efficient operation.

2. Real-Time Data Monitoring: Displays motor parameters, inverter status, alarms, and trend curves.

3. Multiple Protocol Support: Compatible with MODBUS, CANopen, and ABB proprietary communication protocols.

4. High Reliability: Industrial-grade design suitable for high temperature, dust, and humidity environments.

5. Front Panel Protection: IP65 rated for industrial field installation.

6. Easy Installation & Maintenance: Panel-mounted design for quick integration and replacement.

4. Typical Applications

• HMI operation for ABB inverters and PLC control systems

• Industrial automation production line monitoring and control

• Motor drive system parameter setting and monitoring

• Energy management systems (EMS) and distribution control

• HVAC systems, pumps, fans, and other industrial equipment control

5. Installation & Usage Notes

1. Ensure the power supply voltage and interface match the touch panel specifications before installation.

2. Avoid direct sunlight or high-temperature environments; ensure proper ventilation.

3. Installation and wiring should be performed by qualified personnel for safety and reliability.

4. Avoid exposure to liquids, oil, or corrosive gases on the screen.

5. Periodically check touch responsiveness and communication status to ensure long-term stable operation.
