ABB 3BHB020538R0001 High-voltage thyristor module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3BHB020538R0001 High-Voltage Thyristor Module is a high-voltage semiconductor module used in ABB power electronic equipment. It is designed for HVDC transmission, industrial power control, rectification, inversion, and Flexible AC Transmission Systems (FACTS). The module features high current capacity, fast switching characteristics, and reliable thermal management, suitable for demanding industrial and energy applications.

2. Technical Specifications

• Model: 3BHB020538R0001

• Product Type: High-Voltage Thyristor Module

• Polarity/Structure: Single-direction thyristor module

• Maximum Controllable Current: 2000 A (typical, depending on conditions)

• Maximum Blocking Voltage: 3300 V – 5000 V DC (depending on application)

• Triggering Method: Gate Triggered

• Switching Characteristics: Fast turn-on and turn-off

• Insulation Type: Module encapsulated insulation

• Operating Temperature Range: –40 ℃ to +125 ℃

• Thermal Management: Bottom mounting interface for water or air cooling

• Mechanical Mounting: Bolt-fixed installation

• Standards: Compliant with IEC and IEEE power electronics module standards

• Typical Applications: HVDC, rectifier stations, variable frequency drives, FACTS systems, industrial high-voltage equipment

3. Advantages and Features

1. High Current and Voltage Capability
   Handles large industrial loads and high-voltage DC currents.

2. Fast Switching Response
   Provides rapid conduction and turn-off for dynamic power control.

3. Reliable Thermal Management
   Supports water or air cooling to ensure stable long-term operation.

4. Modular Structure
   Easy installation, replacement, and system expansion.

5. Industrial-Grade Reliability
   Operates stably under high temperature, vibration, and high-voltage environments.

4. Applications

• High-Voltage Direct Current (HVDC) transmission systems

• Industrial rectifier stations and power regulation systems

• Thyristor drives and large motor control

• Flexible AC Transmission Systems (FACTS)

• Power electronic equipment

• Heavy industry and energy system high-voltage devices

5. Installation and Usage Notes

1. Verify module model and electrical ratings match system requirements before installation.

2. Follow high-voltage safety procedures to prevent electric shock.

3. Ensure good thermal contact with the heat sink for effective cooling.

4. Observe gate polarity and control circuit connections when wiring.

5. Regularly inspect cooling system and module condition to ensure reliable long-term operation.
