ABB 3BHB003688R0101 High-voltage circuit board
Item NO.:
3BHB003688R0101Payment:
T/TPrice:
$300Product Origin:
SwedenColor:
NEWLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
ABB 3BHB003688R0101 High-Voltage Circuit Board is a core control and power transmission component used in ABB high-voltage switchgear and circuit breakers. The board integrates high-voltage signal control, power switch driving, and protection features to enable reliable operation, fault protection, and status monitoring. It is suitable for high-voltage distribution, industrial power systems, and large-scale power generation equipment. The board is designed with high insulation and voltage resistance for long-term stable and safe operation.
| Parameter | Specification |
|---|---|
| Model | 3BHB003688R0101 |
| Type | High-Voltage Circuit Board |
| Applicable Equipment | High-voltage switchgear, circuit breakers, switchboards |
| Control Type | Integrated digital control and power drive |
| Input Voltage | High-voltage control input, device-specific (typically 3–12 kV and low-voltage signal interfaces) |
| Output Voltage | High-voltage power output, matching switchgear triggering requirements |
| Power Rating | According to device specifications |
| Operating Temperature | –20 ℃ – +70 ℃ |
| Insulation Rating | ≥ 1.2 kV / IEC 60664 |
| Mounting | Installed inside switchgear or panel |
| Protection Class | IP20 (when installed inside cabinet) |
| Standards | IEC 62271, IEC 60664, CE |
| Protection Features | Over-voltage, over-current, short-circuit, thermal overload protection (board and external circuits) |
High Reliability Design
Designed for high-voltage environments with high insulation and voltage tolerance for safe operation.
Integrated Control and Protection
Supports digital control, power driving, and protection functions including overload and short-circuit.
Industrial-Grade Durability
Wide operating temperature range and EMI resistance for long-term operation in high-voltage power systems.
Easy Maintenance and Replacement
Modular design allows fast installation, replacement, or maintenance within switchgear or panel.
High Compatibility
Compatible with ABB high-voltage circuit breakers and switchgear for diverse industrial and power applications.
High-voltage switchgear in distribution systems
Industrial and power plant high-voltage switchboards
Generator and transformer protection and control
High-voltage power automation systems
Transmission lines and substation high-voltage equipment
Large industrial facility power control
Disconnect all high-voltage power before installation or maintenance for safety.
Ensure the circuit board matches the equipment’s rated voltage and current.
Avoid long-term operation in high humidity, high temperature, or high EMI environments.
Regularly inspect terminals, insulation, and operating status for reliable operation.
Follow ABB high-voltage equipment installation and electrical safety standards.
The structure and details of the product：
Please make an inquiry for more models
