ABB 3BHB003230R0101 Drive Board Driver

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview

ABB 3BHB003230R0101 Drive Board Driver
The ABB 3BHB003230R0101 is a drive board module used in ABB low- and medium-voltage drive systems. It primarily controls power semiconductor devices such as IGBTs or MOSFETs, enabling motor drive and speed regulation. The module works with inverters, servo drives, or power modules, providing high-precision PWM signals for smooth motor operation. Industrial-grade design allows operation under high temperature, vibration, and electromagnetic interference.

Technical Specifications

• Model: 3BHB003230R0101

• Module Type: Drive Board / Driver Module

• Applicable Equipment: Low- or medium-voltage inverters / servo drives

• Input Signal: PWM control signal, TTL/CMOS logic level

• Output Drive Capability: Drives IGBT or MOSFET power switches

• Operating Voltage: Typically ±15 V DC (refer to module manual)

• Isolation Method: Optical or electrical isolation

• Operating Temperature: -20℃ to +70℃

• Protection Class: IP20

• Mounting Method: Slot-in module or screw mounting

• Compatibility: ABB ACS or ACSM series drive systems

Advantages and Features

1. High-Precision Control
   Provides stable PWM signals for smooth motor operation and accurate speed regulation.

2. Strong Compatibility
   Works with various ABB inverters, servo drives, and power modules.

3. Industrial Reliability
   Supports high temperature, vibration, and electromagnetic interference for long-term reliability.

4. Modular Design
   Easy to replace and maintain, reducing downtime.

5. Overcurrent and Overvoltage Protection
   Built-in protection prevents damage to power devices and enhances system safety.

Typical Applications

• ABB low- or medium-voltage inverter drive systems

• Industrial servo drives and motor speed control

• Motor drives in automated production lines

• Industrial robot motor control

• Conveyor systems, elevators, fans, pumps, and other industrial motor applications

• High-performance motors requiring precise PWM control

Installation & Usage Notes

1. Power Off Before Installation: Ensure power is fully disconnected before installing or removing the drive board.

2. ESD Protection: Observe anti-static precautions to prevent damage to electronic components.

3. Correct Insertion: Insert the module into the slot as specified to avoid poor contact or short circuits.

4. Environmental Conditions: Install in dry, ventilated areas free of high humidity, dust, or corrosive gases.

5. Regular Maintenance: Inspect the interface with power modules and cable connections to ensure stable long-term operation.
