ABB 3ASC25H208 DATX100 pulse transformer board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 3ASC25H208 DATX100 Pulse Transformer Board – Product Information

1. Product Overview

The ABB 3ASC25H208 DATX100 Pulse Transformer Board is a critical module in ABB industrial automation and power electronics systems.
It is used for isolation, transformation, and transmission of current/voltage pulse signals, ensuring stable and reliable signal transmission with high EMI resistance, suitable for high-voltage and complex industrial environments.

2. Technical Specifications

• Model: 3ASC25H208

• Module Name: DATX100 Pulse Transformer Board

• Input Signal: Pulse voltage/current

• Output Signal: Pulse voltage/current (isolated output)

• Insulation Voltage: Max 3 kV

• Frequency Response: DC to 10 MHz

• Impedance: 50 Ω

• Operating Temperature: -20 ℃ to +70 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Humidity: 5%–95%, non-condensing

• Protection Class: IP20

• Mounting: DIN rail or board mounting

• Dimensions: Approx. 120 × 100 × 30 mm

• Weight: Approx. 0.5 kg

• Certifications: CE, UL

3. Features and Advantages

1. High-precision signal transmission for stable and isolated pulse signals.

2. Strong EMI resistance suppresses electromagnetic interference and noise.

3. Industrial-grade design resistant to dust, moisture, and high voltage environments.

4. Wide frequency response supports DC to high-frequency pulse signals.

5. Easy integration with DIN rail or board mounting.

6. Lightweight design for installation in limited space.

4. Application Areas

• ABB automation and power electronics systems

• Industrial pulse signal isolation and transmission

• High-voltage measurement and protection systems

• Generator excitation and substation control systems

• Industrial automation in power, metallurgical, petrochemical, and manufacturing industries

5. Precautions

1. Install and wire the module only when power is off.

2. Ensure input and output signals are within rated range to avoid damage.

3. Maintain good ventilation and avoid overheating.

4. Avoid long-term use in humid or corrosive environments.

5. Regularly inspect wiring and mounting to prevent poor contact or loosening.

6. Operation and maintenance should be performed by qualified electrical personnel.
