ABB 3ADT315100R1001 power board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Product Overview:

The ABB 3ADT315100R1001 Power Board is a high-performance power module designed for ABB control and drive systems. It provides stable DC power to control, signal, and drive circuits with built-in voltage regulation, overload protection, and EMI suppression. Its industrial-grade design ensures reliable operation even under harsh environments such as high temperature, vibration, dust, and electromagnetic interference, making it a critical component of ABB’s automation and DCS solutions.

Technical Specifications:

• Model: 3ADT315100R1001

• Brand: ABB

• Type: Power Board

• Input Voltage: 24 V DC nominal

• Input Range: 18 – 30 V DC

• Output Voltage: +5 V DC / +15 V DC / -15 V DC

• Output Current: 5V/3A, ±15V/0.5A (typical)

• Ripple: ≤50 mV

• Efficiency: ≥85%

• Protection: Overvoltage, overcurrent, short-circuit

• Cooling: Natural convection

• Interface: Multi-pin connector to main board

• Installation: Plug-in type

• Material: Aluminum base with epoxy coating

• Protection Class: IP20

• Operating Temperature: 0°C to +70°C

• Storage Temperature: -25°C to +85°C

• Humidity: 5% – 95% (non-condensing)

• Dimensions: Approx. 180 × 100 × 30 mm

• Weight: Approx. 350 g

• Compliance: CE, RoHS, IEC 61131
