ABB 2TLA020054R0500 (20-054-05) Connecting block

1. Product Overview

The ABB 2TLA020054R0500 Connecting Block is an electrical connection component for low-voltage distribution and control systems, providing secure and reliable wire connections.
It features a compact design, easy wiring, excellent conductivity, and insulation, widely used in distribution panels, control panels, and automation equipment for efficient system wiring and maintenance.

2. Technical Specifications

• Model: 2TLA020054R0500

• Part Number: 20-054-05

• Type: Connecting Block / Terminal Block

• Rated Voltage (Ue): 690 V AC

• Rated Current (Ie): 41 A

• Poles: 5

• Wire Range: 0.5–10 mm² (copper conductors)

• Mounting: Screw terminal

• Insulation Material: Flame-retardant plastic

• Protection Class: IP20

• Operating Temperature: ‑25 ℃ – +70 ℃

• Mounting Type: DIN rail 35 mm

• Standards Compliance: IEC 60947-7-1 / UL 1059

3. Key Advantages & Features

1. Reliable Electrical Conductivity
   Copper conductor ensures low-resistance connection and stable current flow.

2. Multi-Pole Design
   5 poles allow multiple wires to be connected efficiently in a compact space.

3. Safe Insulation Material
   Flame-retardant plastic housing provides insulation and mechanical protection.

4. Secure Fastening
   Screw terminals ensure wires remain tight, preventing loose connections.

5. Easy Installation
   DIN rail mounting design allows quick installation and replacement.

6. Wide Applicability
   Suitable for distribution panels, control panels, and industrial automation systems.

4. Typical Applications

• Low-voltage distribution system wiring

• Industrial control panels and automation equipment

• Motor control cabinets and drive systems

• Instrumentation and sensor connections

• Building electrical distribution and lighting control

5. Installation & Usage Notes

1. Wire Specification Matching
   Ensure wire cross-section matches terminal specifications to prevent overloading or poor contact.

2. Tightening Check
   After installation, ensure screws are properly tightened to avoid loosening due to vibration.

3. Environmental Conditions
   Avoid high humidity, corrosive gases, and dust to maintain terminal reliability.

4. Prevent Overload
   Do not exceed rated current and voltage to avoid heating or damage.

5. Periodic Inspection
   Check terminal tightness and insulation regularly to ensure safe operation.
