ABB 2TLA020051R5400 Non-contact safety sensor

•

• ABB 2TLA020051R5400 Non-contact Safety Sensor

  1. Product Overview

  The ABB 2TLA020051R5400 is a high-reliability non-contact safety sensor designed for industrial automation and machine safety applications. It monitors safety doors, guards, or other protective devices and provides status feedback to the control system via OSSD (Output Signal Switching Device) safety outputs. Non-contact operation eliminates mechanical wear, extends lifespan, and enhances system safety. The sensor is suitable for high-safety-level systems (PL e / SIL 3).

  2. Technical Specifications

  • Model: 2TLA020051R5400

  • Type: Non-contact Safety Sensor

  • Series: Eden Dynamic Series

  • Rated Control Voltage: 24 V DC

  • Output Type: Dual OSSD safety outputs + status output

  • Sensing Distance: Max approx. 15 mm

  • Connection: M12-5 female connector (5-pin)

  • Rated Operating Current: Approx. 30 mA

  • Protection Rating: IP67 / IP69K (dust and water resistant)

  • Operating Temperature: -40 °C to +70 °C

  • Housing Material: High-strength engineering plastic (PBT)

  • Mounting: DIN rail or panel mount

  • Certification: TÜV Süd certified, suitable for UL/CSA systems

  3. Advantages and Features

  1. Non-contact Detection: Senses position via magnetic or proximity detection without mechanical contact, reducing wear and maintenance.

  2. High Safety Output: OSSD outputs meet industrial safety standards and can interface with safety relays or safety PLCs.

  3. Robust and Durable: IP67 / IP69K protection suitable for industrial environments including moisture, dust, and washdown conditions.

  4. Wide Temperature Range: Operates reliably from -40 °C to +70 °C.

  5. Compact and Flexible: Small form factor with 360° adjustable mounting for tight spaces.

  4. Typical Applications

  • Safety interlocks for doors and guards

  • Industrial machine position monitoring and safety interlocks

  • Automation production line safety protection

  • Packaging, assembly, and robotic systems safety detection

  • High-safety-level industrial control systems (PL e / SIL 3)

  5. Installation and Usage Notes

  • Ensure power is off before installation; confirm 24 V DC supply.

  • Must be used with compatible actuators (e.g., Eden Eva series) for reliable detection.

  • Follow wiring diagrams and safety regulations during installation.

  • Avoid placing sensor near strong magnets or metallic interference.

  • Regularly inspect wiring, output signals, and sealing to ensure reliable operation.

•

The structure and details of the product：
