ABB 2CSM222531R1000 Digital Time Switch

1. Key Parameters

• Product Model: 2CSM222531R1000
• Order Code: 2CSM222531R1000
• Product Series: ABB Digital Time Switch Series (7-day programmable, LCD display)
• Core Function: Controls electrical loads via pre-programmed time schedules; supports daily/weekly cycles, holidays, and manual override; provides real-time clock with battery backup; ensures accurate time-based switching for energy management
• Electrical Specifications:

  Parameter	Details	Performance Metrics
  Power Supply	AC 230V ±10% (50Hz/60Hz auto-adaptive); Power consumption: ≤3VA	Compatible with standard low-voltage grids
  Output Capacity	16A (resistive load, AC 250V); 8A (inductive load, AC 250V, cosφ=0.6)	Handles medium-power loads (e.g., 4kW lighting systems)
  Timing Accuracy	±1 minute/month (at 25℃); Temperature drift: ≤±3 seconds/℃	Ensures precise schedule execution
  Program Capacity	50 on/off events; 8 weekly programs; 10 holiday settings	Flexible for complex scheduling needs
  Time Settings Range	- Daily/weekly cycles - Minute-level resolution (1-minute increments) - Countdown timer: 1 minute~168 hours - Astronomical clock (sunrise/sunset based on location)	Adapts to diverse application requirements
  Backup Power	CR2032 lithium battery (3V); Backup duration: ≥3 years (power off)	Maintains clock and programs during power outages

• Mechanical Specifications:
  • Housing Material: Flame-retardant polycarbonate (UL94 V-0); IP40 front panel protection
  • Dimensions (W×H×D): 72mm × 72mm × 55mm (standard DIN 43880 panel cutout)
  • Mounting: Panel-mounted (cutout size: 67mm × 67mm); secured with 4 M3 screws (torque: 0.8 N·m)
  • Weight: Approximately 180g
  • User Interface: 128×64 pixel LCD display (backlit); 4 navigation buttons; 1 manual override switch
  • LED Indicator: Green (output active); Red (program error/backup low)
• Environmental Ratings:
  • Operating Temperature Range: -5℃~+55℃ (23℉~131℉)
  • Storage Temperature Range: -20℃~+70℃ (-4℉~158℉)
  • Humidity Tolerance: ≤95% RH (non-condensing, 40℃; suitable for damp environments)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no program loss)
  • Shock Resistance: 15g acceleration (11ms duration, IEC 60068-2-27; maintains clock accuracy)
• Compliance Standards: IEC 61038 (time switches), EN 61000-6-2 (EMC immunity), UL 60730-1 (household electrical appliances), CE, RoHS

2. Key Features

• Flexible Programming: Supports 50 on/off events, 8 weekly programs, and 10 holiday settings—accommodates complex schedules (e.g., different weekday/weekend lighting times in offices, seasonal adjustments for heating systems).
• Astronomical Clock Function: Automatically adjusts switching times based on sunrise/sunset (configurable by latitude/longitude)—ideal for outdoor lighting (e.g., parking lot lights, building facades) to optimize energy use.
• High Timing Accuracy: ±1 minute/month drift ensures reliable schedule execution, avoiding premature/delayed switching (critical for time-sensitive applications like factory production line pre-heating).
• Battery Backup: 3-year CR2032 battery maintains clock and programs during power outages—eliminates re-programming after grid failures, ensuring uninterrupted operation.
• User-Friendly Interface: Backlit LCD display and intuitive 4-button navigation simplify programming (no specialized training required); supports multiple languages (English, German, French, Spanish, etc.).
• Manual Override: Dedicated switch allows temporary bypass of programmed schedules—convenient for maintenance (e.g., keeping lights on during evening repairs) without altering stored programs.
• Wide Load Compatibility: 16A resistive/8A inductive capacity directly controls medium-power loads (e.g., 4kW lighting, 2.5kW pumps) without external contactors—reduces system complexity and cost.

3. Application Fields

• Commercial & Industrial Lighting Control: Primary application—automated lighting management:
  • Office Buildings: Controls fluorescent/LED lighting systems; programs "working hours" (8:00~18:00) for weekdays and "reduced hours" (9:00~12:00) for weekends, cutting energy consumption by 30% compared to manual switching.
  • Parking Lots & Warehouses: Uses astronomical clock to activate outdoor lighting 30 minutes before sunset and deactivate 30 minutes after sunrise; 8A inductive capacity handles LED floodlights with drivers.
• HVAC & Energy Management: Optimizes heating/cooling operation:
  • Shopping Malls: Regulates air conditioning systems—starts 1 hour before opening (9:00) and stops 1 hour after closing (22:00); holiday settings disable operation on public holidays, reducing energy waste.
  • Factory Production Lines: Pre-heats industrial ovens 30 minutes before shift start (7:30) and shuts down heating after shift end (17:30); precise timing ensures equipment readiness while minimizing idle energy use.
• Residential & Infrastructure Auxiliaries: Automates household and public services:
  • Residential Complexes: Controls communal area lighting (corridors, stairwells) with "night mode" (22:00~6:00) at reduced brightness; manual override allows residents to extend lighting as needed.
  • Water Supply Systems: Activates booster pumps for 2-hour intervals (6:00~8:00, 18:00~20:00) during peak water usage, avoiding continuous operation and reducing pump wear.
• Agricultural & Horticultural Systems: Manages cultivation environments:
  • Greenhouses: Controls irrigation pumps and grow lights—12-hour light cycles (6:00~18:00) for plant growth, with adjustable schedules for different crop stages; ensures consistent growing conditions.

The structure and details of the product：
