ABB 2CPX030101R9999 Compact Wiring Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us

1. Product Overview

The ABB 2CPX030101R9999 Compact Wiring Board is a compact internal wiring solution designed for distribution boards and control cabinets. It enables organized wiring and reliable electrical connections inside panels, improving wiring efficiency, safety, and ease of maintenance. It is widely used in low-voltage distribution and industrial control systems.

2. Technical Specifications

• Model: 2CPX030101R9999

• Product Name: Compact Wiring Board

• Product Type: Internal wiring component for electrical panels

• Rated Insulation Voltage (Ui): 690 V

• Rated Current: Up to 125 A depending on terminal configuration

• Mounting Method: Screw fixing or DIN rail integration

• Applicable Conductor Cross-Section: 0.5 mm² – 35 mm² (depending on terminal type)

• Material: Flame-retardant insulation + tin-plated copper conductors

• Flammability Rating: UL94 V-0

• Operating Temperature Range: -25°C to +70°C

• Protection Degree: IP20 (when installed inside enclosure)

• System Compatibility: Single-phase and three-phase systems

• Standards: IEC 61439, IEC 60947 related requirements

3. Features & Advantages

1. Compact and Space-Saving
   Optimized for compact distribution boards and control cabinets.

2. High Connection Reliability
   High-conductivity copper bars and quality terminals reduce contact resistance and heat.

3. Easy Installation
   Modular design for fast mounting and replacement.

4. Enhanced Safety
   Flame-retardant housing materials improve fire safety performance.

5. Convenient Maintenance
   Well-organized wiring layout for easy inspection and servicing.

4. Typical Applications

• Low-voltage distribution boards

• Industrial automation control panels

• Building electrical distribution systems

• Machinery electrical control cabinets

• Data center power distribution

• Renewable energy distribution and control systems

5. Installation & Safety Notes

1. Installation by Qualified Personnel Only
   Must comply with local electrical standards.

2. Disconnect Power Before Installation
   Ensure the system is de-energized before servicing.

3. Use Proper Conductor Size
   Select cable cross-section according to rated current.

4. Ensure Tight Connections
   Periodically check terminal tightness to avoid overheating.

5. Suitable Environment Required
   Install inside a dry, ventilated electrical enclosure.
