ABB 2CDS383001R0024 Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

•

• 1. Product Overview

  The ABB 2CDS383001R0024 is a high-performance Miniature Circuit Breaker (MCB) from the ABB S800 series, designed for low-voltage distribution system protection. It provides reliable overload and short-circuit protection, quickly disconnecting circuits when abnormal current occurs to protect equipment and personnel. This model is triple-pole (3P), rated 1 A, with B-type trip characteristics, suitable for residential, commercial, and light industrial loads.

  ---

  2. Technical Specifications

  Parameter	Specification
  Series	ABB S800
  Model	2CDS383001R0024
  Poles	3P (Triple Pole)
  Rated Current	1 A
  Trip Type	B Type (for resistive and light inductive loads)
  Rated Voltage	230/400 V AC
  Breaking Capacity	6 kA
  Mounting	DIN rail (35 mm)
  Terminals	Screw terminals, suitable for copper/aluminum wires
  Mechanical Life	≥ 10,000 operations
  Electrical Life	≥ 4,000 operations
  Operating Temperature	-25 ℃ ~ +40 ℃
  Protection Rating	IP20
  Standards	IEC/EN 60898-1 / IEC/EN 60947-2

  ---

  3. Key Features and Benefits

  • Reliable protection: Fast response to overload and short-circuit conditions.

  • Compact design: DIN rail mounting for space-saving installation.

  • High breaking capacity: Withstands up to 6 kA short-circuit current.

  • Easy installation and maintenance: DIN rail clip for quick installation and removal.

  • Standard compliance: Meets IEC/EN standards for residential, commercial, and light industrial applications.

  ---

  4. Typical Applications

  • Residential, commercial, and office building circuits

  • Lighting and socket branch circuits

  • Small machinery and control system protection

  • Branch circuit protection inside distribution boards

  • Light industrial load protection

  ---

  5. Installation & Usage Notes

  1. Proper selection: Choose appropriate rated current according to load.

  2. Correct wiring: Connect main circuits according to wiring diagram; ensure terminals are tight.

  3. Environmental considerations: Avoid high temperature, humidity, and corrosive environments.

  4. Regular inspection: Check mechanical operation and terminals to ensure safe long-term operation.

•
•

The structure and details of the product：
