ABB 2CDS211001R0104 Miniature Circuit Breaker

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 2CDS211001R0104 is a single-pole miniature circuit breaker (MCB) from the ABB SH200 series. It provides protection against overload and short-circuit faults in AC distribution circuits. The breaker features both thermal trip (overload) and electromagnetic trip (short-circuit) mechanisms, allowing fast disconnection of abnormal currents, preventing wiring damage and fire hazards. It is suitable for residential, commercial, and light industrial low-voltage distribution systems.

2. Technical Specifications

• Model: 2CDS211001R0104

• Series/Name: SH201‑C10 Miniature Circuit Breaker

• Poles: 1P (single pole)

• Rated Current: 10 A

• Trip Curve: C‑type (suitable for inductive loads)

• Rated Operational Voltage: 230 V AC

• Rated Insulation Voltage Ui: 440 V

• Rated Short-Circuit Breaking Capacity Icn: 6 kA

• Impulse Withstand Voltage Uimp: 4 kV

• Frequency: 50 / 60 Hz

• Mounting: DIN rail

• Terminal Connection: Screw terminals

• Connectable Wire Size: Solid 0.75–25 mm², stranded 0.75–16 mm²

• Width: 1 module (17.5 mm)

• Operating Temperature: ‑25 ℃ to +55 ℃

• Protection Class: IP20

• Standards: IEC/EN 60898‑1

• Durability: ~20,000 mechanical/electrical cycles

3. Key Advantages & Features

• Dual Trip Mechanisms – Combines thermal delayed trip and electromagnetic instantaneous trip for overload and short-circuit protection.

• C-Curve Characteristic – Handles 5–10× rated current inrush, suitable for inductive loads, reducing nuisance trips.

• Compact Design – 17.5 mm width saves space for dense panel installation.

• High Breaking Capacity – 6 kA interrupting rating suitable for residential and light industrial circuits.

• Wide Operating Temperature – Reliable operation from ‑25 ℃ to +55 ℃.

• International Standards Compliance – Meets IEC/EN 60898‑1 for global low-voltage AC systems.

4. Typical Applications

• End-circuit protection in residential and apartment installations

• Circuit protection for commercial buildings (lighting, sockets)

• Small office distribution boards

• Light industrial assembly lines and terminal equipment protection

• Distribution panels and control cabinet end circuits

• Any low-voltage AC system requiring 10 A overload and short-circuit protection

5. Installation & Usage Notes

• Correct Rating Selection – Ensure breaker rating matches the load to avoid nuisance trips or protection failure.

• DIN Rail Mounting – Secure mounting on standard TH35 rails.

• Proper Terminal Connections – Tighten screws to recommended torque to prevent poor contact and overheating.

• Environmental Considerations – Avoid prolonged exposure to high humidity, dust, or corrosive environments.

• Periodic Maintenance – Inspect appearance, wiring, and trip events for reliable operation.

• Do Not Mix Different Types – Avoid installing different trip characteristic breakers in parallel on the same rail without isolation.
