ABB 2097-V33PR6 Servo Drive/Servo Control Module

• 1. Product Overview

  ABB 2097-V33PR6 Servo Drive/Servo Control Module is a high-performance motion control device for ABB servo systems, providing precise position and speed control. The module integrates advanced control algorithms and digital signal processing, enabling high dynamic response, accurate positioning, and low-vibration operation.

  2097-V33PR6 is suitable for robots, packaging machines, CNC machines, and automated production lines. It seamlessly integrates with ABB servo motors and control systems, delivering efficient and reliable motion control.

  ---

  2. Main Technical Data

  General

  • Product type:
    Servo Drive/Servo Control Module

  • Model:
    2097-V33PR6

  • Control method:
    Position, speed, and torque closed-loop control

  • Input power:
    3×380–480 V AC, 50/60 Hz

  • Control signal interface:
    Analog input, digital I/O, encoder feedback

  • Communication interface:
    DeviceNet, EtherCAT, PROFINET (optional, system dependent)

  • Output power:
    0–3 kW (depending on motor match)

  Electrical Characteristics

  • Rated current:
    6 A (typical, depends on motor and load)

  • Overload capacity:
    150% for 60 seconds

  • Control accuracy:
    ±0.01° (position closed-loop, depending on motor)

  • Response frequency:
    Up to 2 kHz (position closed-loop)

  Mechanical & Environment

  • Mounting:
    DIN rail or panel inside control cabinet

  • Housing:
    Industrial-grade metal with good heat dissipation

  • Operating temperature:
    0°C to +55°C

  • Protection rating:
    IP20 (standard installation)

  • Dimensions (mm):
    Compact, suitable for control cabinet layout

  Standards & Certification

  • Compliance:
    IEC 61800-5-1, IEC 60947-4-1, CE

  • Operating environment:
    Industrial automation, robotics, CNC machines, high-speed production lines

  ---

  3. Key Advantages and Features

  1. High-precision motion control
     Supports position, speed, and torque closed-loop control for accurate and low-vibration operation.

  2. High dynamic response
     DSP and advanced algorithms enable fast response and high dynamic performance.

  3. Flexible interfaces and expandability
     Supports multiple communication protocols and I/O interfaces for seamless integration.

  4. Modular and compact design
     Easy installation, maintenance, and upgrade; seamless integration with ABB servo motors.

  5. Reliable and durable
     Industrial-grade housing and heat dissipation design withstands high temperature, vibration, and harsh environments.

  6. Safety and protection
     Built-in overload, overvoltage, short-circuit protection, and encoder monitoring enhance system safety.

  ---

  4. Typical Applications

  • Industrial robot motion control

  • Automated production line servo drive

  • Packaging machinery and high-speed handling equipment

  • CNC machines and automated machining centers

  • Printing, textile, and electronics manufacturing equipment

  • Precision control of fans, pumps, and actuators

  ---

  5. Installation and Application Notes

  1. Verify motor match and rated power
     Ensure the drive module matches the servo motor specifications to prevent overload.

  2. Correct wiring
     Connect power, encoder, and control signals according to the manual; avoid miswiring.

  3. Environmental conditions
     Install in a dry, ventilated environment without corrosive gases; ensure proper heat dissipation.

  4. Cooling and ventilation
     Ensure sufficient space for module heat dissipation to prevent overheating.

  5. Regular inspection and maintenance
     Check terminal connections, module status, and communication signals for long-term stable operation.

•
•
