ABB 1SVR630660R0100 Insulation Monitoring Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SVR630660R0100 Insulation Monitoring Relay continuously monitors insulation resistance in unearthed (IT) DC or AC systems. When insulation resistance drops below a preset threshold, the relay triggers an alarm to alert maintenance personnel, preventing equipment damage, fire hazards, and electric shock. The relay supports single- or three-phase monitoring, adjustable alarm thresholds, delay functions, and multiple output configurations, widely used in industrial, power, and infrastructure systems.

2. Technical Specifications

3. Key Features & Advantages

• Continuous insulation monitoring for early fault detection

• Adjustable alarm thresholds for flexible application

• Fast response down to 200 ms for safety-critical systems

• Multiple output configurations for alarms, interlocks, or remote monitoring

• Wide voltage compatibility for AC and DC IT systems

• Compact DIN rail design for easy panel integration

• Industrial standard certified to IEC 61557‑8 for electrical safety

4. Typical Applications

• Industrial IT system insulation monitoring

• Power plants, substations, and distribution systems

• Medical equipment supply systems

• Data centers and communication base station IT systems

• Elevators, rail transport, and infrastructure electrical protection

• Automation and factory control panels

5. Installation & Safety Notes

1. Correct wiring: Connect input terminals to the IT system properly to avoid measurement errors.

2. Set alarm threshold: Adjust insulation resistance alarm value according to system requirements.

3. Environmental conditions: Install in dry, ventilated areas free from dust, moisture, or corrosive gases.

4. Regular inspection: Test insulation monitoring function and relay outputs periodically.

5. Power supply matching: Ensure supply voltage matches the relay model to avoid damage.

6. Complementary protection: Use with breakers, fuses, or other protection devices for overall system safety.
