ABB 1SVR405659R1000 Miniature relay socket plastic bracket

•

• 1. Product Overview

  The ABB 1SVR405659R1000 Miniature Relay Socket Plastic Bracket is designed for ABB S-series miniature relays, providing secure mounting and electrical connection. Made of high-quality engineering plastic, the socket offers excellent insulation and mechanical strength, ensuring safe and reliable relay operation in control systems.

  It is widely used in low-voltage control circuits, industrial automation systems, and electromechanical equipment for relay installation and wiring.

  ---

  2. Technical Specifications

  • Model: 1SVR405659R1000

  • Type: Miniature Relay Socket (Plastic Bracket)

  • Compatible Relay Series: ABB S-series miniature relays

  • Material: High-strength engineering plastic (flame-retardant, excellent insulation)

  • Number of Poles: Universal (single relay mounting)

  • Mounting: 35 mm DIN rail

  • Operating Temperature: -25 to +70 °C

  • Storage Temperature: -40 to +85 °C

  • Protection Rating: IP20

  • Dimensions (L × W × H): 45 × 28 × 25 mm

  • Weight: ~15 g

  • Electrical Connection: Plug-in or screw terminals for coil and load connections

  ---

  3. Key Advantages & Features

  1. High Insulation Performance
     Flame-retardant plastic material prevents short circuits and ensures safe operation.

  2. Easy Installation
     Supports DIN rail mounting; relays can be easily plugged or removed for maintenance.

  3. Compact Design
     Saves space and allows dense wiring in control panels with modular layouts.

  4. High Reliability
     Heat-resistant and impact-resistant materials ensure stable long-term performance.

  5. Wide Compatibility
     Compatible with various ABB miniature relay models for flexible control circuit applications.

  ---

  4. Typical Applications

  • Industrial automation control systems

  • Relay installation in distribution and control panels

  • Electromechanical equipment control and protection

  • HVAC system control

  • Motor control circuits and signal isolation

  ---

  5. Installation & Usage Notes

  1. Ensure the socket is securely mounted on the DIN rail to prevent loosening.

  2. Verify wiring connections to avoid malfunction or relay failure.

  3. Avoid using in high humidity, corrosive gases, or dusty environments.

  4. Power off before inserting or removing relays for safety.

  5. Periodically check the socket’s mounting and insulation condition to ensure long-term reliability.

•
