ABB 1SVR405613R3000 Interface Relay Module

Product Information: ABB 1SVR405613R3000 Interface Relay Module

Detailed Specifications:

• Model: 1SVR405613R3000

• Type: Interface Relay Module

• Input Voltage: 24 V DC (operating voltage range: 20.4 V to 28.8 V)

• Output Voltage: 250 V AC / 30 V DC (rated voltage of relay contacts)

• Rated Current: 8 A (rated current of relay contacts)

• Contact Configuration: 1 NO (Normally Open contact)

• Number of Relays: 1 relay (single channel)

• Response Time: < 10 ms (from input signal to relay activation)

• Operating Temperature Range: -20°C to +60°C

• Storage Temperature Range: -40°C to +85°C

• Mounting Type: DIN rail mount (35mm standard DIN rail)

• Dimensions: 90mm x 22.5mm x 114mm

• Protection Rating: IP20

• Certifications: CE, UL, RoHS

• Weight: 0.1 kg

Product Advantages and Features:

1. High-Performance Interface Relay: The ABB 1SVR405613R3000 interface relay module provides stable and fast signal conversion, widely used in industrial automation and control systems with efficient data processing capability.

2. Wide Application Compatibility: Supports 24 V DC input voltage, compatible with various industrial control systems and equipment, especially suitable for automation control, remote monitoring, and data transmission applications.

3. High Reliability Design: Offers long-term stable operation with excellent anti-interference performance, ensuring reliable operation in harsh industrial environments.

4. Fast Response Time: With a response time of less than 10 ms, it enables fast signal transmission and quick action, ensuring real-time system response.

5. Compact Design: The relay module has a compact design with dimensions of 90mm x 22.5mm x 114mm, making it suitable for space-constrained electrical cabinets and automation control systems.

6. Easy Installation and Maintenance: Supports standard DIN rail mounting, making installation and replacement simple, reducing maintenance difficulty and downtime.

7. High Temperature Adaptability: Operates reliably within the temperature range of -20°C to +60°C, making it suitable for a wide range of industrial environments.

Applications:

• Industrial Automation Systems: Used in industrial automation control systems for signal conversion and relay control, supporting communication between devices, machines, and PLCs.

• Remote Monitoring and Data Transmission: Ideal for remote monitoring and data acquisition systems for signal conversion, providing fast and stable signal transfer.

• Energy Management: Used in power systems for controlling and monitoring the status of electrical equipment, ensuring safe operation.

• Building Automation: Applied in building control systems for managing lighting, power, HVAC, and other equipment through signal conversion.

• Process Control Systems: Used in industries like chemicals and pharmaceuticals as a signal intermediary, ensuring stable and accurate signal transmission during automated processes.

Precautions:

1. Stable Power Supply: Ensure the module is supplied with stable 24 V DC power to avoid relay failures or system instability due to voltage fluctuations.

2. Environmental Suitability: The module is suitable for industrial environments, but should be protected from prolonged exposure to high humidity, corrosive gases, or extreme conditions to extend its lifespan.

3. Correct Wiring: Ensure correct wiring of input and output terminals to prevent module damage or system instability due to incorrect connections.

4. Regular Inspections: Periodically check the relay's contact points for wear, ensuring the device is functioning properly and preventing contact failure over time.

5. Installation Requirements: Ensure proper installation in environments that meet the operating conditions and use standard DIN rail mounting for secure attachment, preventing performance issues from improper installation.
