Product Overview

ABB 1SVR011775R2600 Universal Measuring Transducer
The ABB 1SVR011775R2600 is a high-precision universal measuring transducer designed to convert electrical quantities (such as current, voltage, and power) into standard output signals for monitoring and data acquisition in PLCs, DCS, or other control systems. It features fast response, accurate measurement, and compact design, suitable for distribution systems, industrial automation, and energy management applications.

Technical Specifications

• Model: 1SVR011775R2600

• Device Type: Universal Measuring Transducer

• Input Signal: AC/DC current, voltage (range dependent)

• Output Signal: 4–20 mA / 0–10 V (optional)

• Supply Voltage: 24 V DC or 230 V AC (model dependent)

• Accuracy: 0.5% FS

• Response Time: ≤ 200 ms

• Operating Temperature: -20℃ to +60℃

• Mounting Method: DIN rail

• Protection Class: IP20

• Standards & Certifications: IEC 60688 / EN 60688

Advantages and Features

1. High-Precision Measurement
   Accurately measures current, voltage, and power for precise control applications.

2. Standard Signal Output
   Provides 4–20 mA or 0–10 V output compatible with various control systems.

3. Fast Response
   Short response time suitable for dynamic monitoring and fast control.

4. Modular Compact Design
   Space-saving for installation in distribution panels or control cabinets.

5. Wide Applicability
   Suitable for power distribution, industrial automation, energy management, and building automation.

Typical Applications

• Low-voltage distribution system monitoring

• PLC/DCS system signal acquisition

• Monitoring of motors, transformers, and load power

• Energy management systems and building automation

• Factory automation process control

Installation & Usage Notes

1. Power Off Before Installation: Disconnect power before installation or maintenance.

2. Signal Matching: Input range must match the transducer to avoid measurement errors.

3. Environmental Conditions: Install in ventilated, dry areas; avoid corrosive gases and dust.

4. Wiring Guidelines: Connect input, output, and power according to wiring diagram.

5. Regular Inspection: Check wiring, output signals, and device status for long-term reliable operation.
