1. Product Overview

The ABB 1SFL487002R1300 is an industrial Three‑Phase AC Contactor designed for controlling three‑phase motors, power distribution, load switching, and automation systems. Featuring a robust electromagnetic mechanism and high‑quality contacts, this contactor delivers fast switching, strong arc resistance, and long service life. It is suitable for frequent operation in industrial environments and is a key component in electrical control panels and systems.

2. Technical Specifications

The following values are typical for this model; refer to actual product documentation for precise specification:

• Model: 1SFL487002R1300

• Product Type: Three‑Phase AC Contactor

• Rated Operating Voltage: AC 690 V

• Rated Current: 65 A (variant dependent)

• Number of Poles: 3 poles

• Main Contacts: 3 Normally Open (3 NO)

• Auxiliary Contacts: Optional based on version

• Coil Control Voltage: AC 24 V / 48 V / 110 V / 230 V options

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 300,000 operations (rated load)

• Make/Break Time: ~ 20–40 ms

• Operating Temperature: -25 ℃ to +60 ℃

• Degree of Protection: IP20

• Mounting: DIN rail or bolt mount

• Standards: IEC 60947‑4‑1

• Dimensions (Approx.): Width ~ 71.5 mm × Height ~ 110 mm × Depth ~ 85 mm

3. Advantages & Features

1. High Durability & Reliability
   Industrial‑grade construction and material quality support frequent operation and harsh environments.

2. Strong Arc Withstand & Shock Resistance
   Contact design and material reduce arc damage and extend service life.

3. Multiple Coil Voltages Available
   Offers multiple control voltage options to suit various control systems.

4. Modular & Expandable
   Can be combined with auxiliary blocks and overload relays for complete control/protection schemes.

5. Easy Installation & Maintenance
   Supports both DIN rail and panel mounting for flexible installation.

6. International Compliance
   Complies with IEC 60947 series standards for global electrical applications.

4. Application Areas

The ABB 1SFL487002R1300 Three‑Phase Contactor is widely used in:

• Three‑phase motor start/stop control

• Industrial automation control systems

• Pumps, fans, compressors, and drive systems

• Machinery manufacturing and production line power control

• HVAC systems

• Power distribution and switchgear

• Building and municipal electrical systems

5. Notes & Precautions

1. Power Off Before Installation: Ensure power is disconnected before installation and wiring.

2. Match Load Ratings: Ensure the contactor voltage and current ratings match the load requirements.

3. Installation Environment: Install in a dry, ventilated area free from excessive dust and corrosive gases.

4. Tight Terminals: Check that all terminations are tight and properly secured.

5. Auxiliary Contacts: If auxiliary contacts are used, ensure they are wired according to the control logic.

6. Periodic Inspection: Regularly inspect contact condition and coil operation for reliability.

7. Qualified Personnel: Installation, commissioning, and maintenance should be performed by qualified electrical engineers.
