ABB 1SDA082810R1 Rotary Handle

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• • 1. Product Overview

    The ABB 1SDA082810R1 is a Rotary Handle Operating Mechanism designed for ABB Tmax XT series Molded Case Circuit Breakers (MCCBs). It provides panel-mounted remote operation and mechanical interlock control, with an adjustable depth handle, door interlock and padlock provisions for enhanced safety and convenience.

    ---

    2. Technical Specifications

    Specification	Description
    Model	1SDA082810R1
    Product Type	Rotary Handle Operating Mechanism
    Compatible With	ABB Tmax XT (XT1 – XT3) MCCBs
    Mounting	Front panel of distribution enclosure
    Return Type	Standard returned
    Handle Length	250 mm (adjustable depth)
    Features	Mechanical interlock, padlock provision
    Application	Fixed and plug-in MCCBs
    Approx. Weight	~0.5 kg
    Standard	Complies with IEC 60947-2

    Note: The handle allows external panel control of MCCB ON/OFF status and supports mechanical safety interlock mechanisms.

    ---

    3. Advantages & Features

    • Convenient Panel Operation: Enables direct ON/OFF control from the distribution panel door.

    • Mechanical Safety Interlock: Includes door interlock and padlock provisions to prevent unintended operation.

    • Adjustable Depth Design: Handle depth can be adjusted to suit enclosure panel thickness.

    • Wide Compatibility: Designed to fit ABB Tmax XT series MCCBs (XT1 – XT3).

    • Industrial-Grade Construction: Robust design for frequent use in demanding environments.

    ---

    4. Typical Applications

    Commonly used in:

    • Industrial power distribution panels

    • Building electrical distribution systems

    • Data center power control

    • Automation control rooms

    • Generators and substation switchgear

    ---

    5. Installation & Safety Notes

    • Ensure installation by qualified electricians.

    • Always work on the MCCB when it is de-energized during installation or adjustment.

    • Verify door interlock and padlock settings are correctly implemented.

    • Perform periodic maintenance checks for wear or loosening.

    • Confirm compatibility with enclosure panel and MCCB model before installation.

  •
•
•
