ABB 1SDA068126R1 Molded Case Circuit Breaker

• ABB 1SDA068126R1 Molded Case Circuit Breaker (MCCB)

  1. Product Overview

  The ABB 1SDA068126R1 is a high-performance Molded Case Circuit Breaker (MCCB) from the SACE Tmax XT4N series, designed for low-voltage distribution systems to protect circuits against overload, short-circuit, and isolation faults. It features an electronic trip unit EKIP LS/I, allowing precise protection settings for safe and stable operation in industrial and commercial power systems.

  2. Technical Specifications

  • Model: 1SDA068126R1

  • Type: Molded Case Circuit Breaker (MCCB)

  • Series: SACE Tmax XT4N

  • Poles: 3‑pole

  • Rated Current: 250 A

  • Rated Operating Voltage: Up to 690 V AC

  • Rated Insulation Voltage (Ui): 1000 V

  • Rated Impulse Withstand Voltage (Uimp): 8 kV

  • Trip Unit: Electronic EKIP LS/I

  • Ultimate Short-Circuit Breaking Capacity (Icu): 65 kA

  • Service Short-Circuit Breaking Capacity (Ics): 65 kA

  • Terminal Connection: Front bolt connection

  • Mounting: Fixed mount

  • Protection Rating: IP20

  • Dimensions (W×D×H): ~105 × 82.5 × 160 mm

  • Weight: ~2.3 kg

  • Frequency: 50 / 60 Hz

  • Standards: IEC 60947 series compliant

  3. Advantages and Features

  1. High Breaking Capacity — 65 kA breaking capacity ensures reliable interruption under industrial short-circuit conditions.

  2. Electronic Trip Unit — EKIP LS/I provides precise overload and short-circuit protection with adjustable settings.

  3. Three-Phase Protection — 3-pole design for three-phase power and distribution loads.

  4. Compact Design — Space-efficient for combination installations in distribution cabinets.

  5. High Reliability — Superior mechanical and electrical performance suitable for frequent operation environments.

  4. Typical Applications

  • Main and feeder protection in industrial distribution boards

  • Motor Control Centers (MCC)

  • Commercial building power distribution

  • Load isolation and safety protection

  • Automation system power distribution and equipment protection

  5. Installation and Usage Notes

  • Ensure power is disconnected before installation for safety.

  • Verify breaker rated current matches system load to avoid nuisance tripping or overload.

  • Follow wiring diagrams and ensure terminal connections are secure.

  • Avoid prolonged use in high humidity, corrosive, or strong electromagnetic interference environments.

  • Regularly inspect terminals, operating mechanisms, and trip unit for long-term reliable operation.

•
•
•
