ABB 1SDA067604R1 Molded Case Circuit Breaker (MCCB)

Product Overview:

The ABB 1SDA067604R1 is a high-performance Molded Case Circuit Breaker (MCCB) from the ABB Tmax T series, designed to provide reliable protection against overloads, short circuits, and under-voltage in low-voltage distribution systems.
It combines compact dimensions, superior breaking capacity, and excellent reliability, making it ideal for industrial, commercial, and infrastructure applications.

Technical Specifications:

• Model: 1SDA067604R1

• Series: ABB Tmax T Series

• Type: Molded Case Circuit Breaker (MCCB)

• Brand: ABB

• Rated Current (In): 250 A

• Rated Operational Voltage (Ue): 690 V AC

• Rated Insulation Voltage (Ui): 1000 V AC

• Rated Impulse Withstand Voltage (Uimp): 8 kV

• Breaking Capacity (Icu): 36 kA @ 415 V AC

• Service Breaking Capacity (Ics): 100% Icu

• Poles: 3P / 4P (optional)

• Frequency: 50 / 60 Hz

• Trip Unit: Thermal-magnetic or electronic

• Adjustable Protection Settings: Long delay / short delay / instantaneous

• Mechanical Life: ≥ 20,000 operations

• Electrical Life: ≥ 10,000 operations

• Mounting: Panel or DIN rail

• Terminal Type: Screw or plug-in terminals

• Enclosure Protection: IP40 (up to IP65 with handle)

• Operating Temperature: -25°C to +70°C

• Standards: IEC 60947-2, UL 489, CSA, CCC

• Weight: Approx. 2.5 kg

Features and Advantages:

1. High Breaking Capacity – Up to 36 kA short-circuit protection.

2. Modular and Flexible Design – Supports a wide range of accessories.

3. Adjustable Trip Settings – Precision protection for various load conditions.

4. Compact and Space-saving – Ideal for modern panel installations.

5. Durable and Safe Construction – Flame-retardant housing and strong arc chambers.

6. Clear Operation Indicators – Ensures safe and reliable manual operation.

7. Easy Maintenance – Quick connection and modular replacement design.

8. International Certifications – Fully compliant with IEC, UL, and CCC standards.

Applications:

• Industrial power distribution systems

• Commercial and infrastructure electrical panels

• Motor and equipment protection

• Data centers and energy systems

• Renewable energy installations (solar, wind)

• Control panels and MCC units

Precautions:

1. Ensure power is disconnected before installation or maintenance.

2. Select appropriate rated current based on actual load.

3. Do not exceed rated voltage or breaking capacity.

4. Regularly inspect and tighten connections.

5. Avoid continuous operation in high-humidity or corrosive environments.

6. Combine with residual current or electronic trip units if required.

7. Install external handle and lockout device per safety standards.

The structure and details of the product：
