ABB 1SDA067414R1 Molded Case Circuit Breaker

Product Information: ABB 1SDA067414R1 Molded Case Circuit Breaker

Detailed Specifications:

• Model: 1SDA067414R1

• Type: Molded Case Circuit Breaker (MCCB)

• Rated Voltage: 690 V AC

• Rated Current: 32 A to 1600 A

• Short Circuit Breaking Capacity: 50 kA (varies depending on model)

• Rated Frequency: 50/60 Hz

• Overload Protection Setting: Adjustable

• Contact Type: 1 Normally Open (NO) contact

• Protection Features: Overload protection, short circuit protection, undervoltage protection

• Mounting Type: DIN rail mount, bolt-on mount

• Dimensions: Varies with rated current

• Weight: Varies with rated current

• Ingress Protection: IP20

• Certifications: CE, UL, TÜV, CCC (compliant with international and regional safety certifications)

Product Advantages and Features:

1. High Breaking Capacity: The ABB 1SDA067414R1 molded case circuit breaker offers a high short circuit breaking capacity, efficiently handling sudden short-circuit conditions to protect the electrical system from damage.

2. Adjustable Overload Protection: The breaker features adjustable overload protection, allowing users to customize settings according to actual load requirements, ensuring timely disconnection of power when the load is too high, preventing damage to equipment.

3. Multiple Protection Functions: In addition to overload protection, the 1SDA067414R1 also includes short circuit protection and undervoltage protection, offering multiple layers of safety to prevent system failures.

4. High Reliability and Durability: Manufactured with high-quality materials and advanced processes, ensuring long-term stable and reliable performance in various industrial environments with harsh conditions.

5. Flexible Installation: Supports both DIN rail and bolt-on mounting options, making installation more flexible and adaptable to different electrical control systems and distribution panel environments, reducing installation complexity.

6. Environmental and Energy Efficiency: Compliant with environmental standards, offering excellent energy efficiency, suitable for modern green buildings and industrial facilities.

Applications:

• Power Distribution Systems: Widely used in electrical protection systems to safeguard equipment from overloads, short circuits, and abnormal currents, ensuring the stable operation of power systems.

• Industrial Automation: Used in industrial automation systems to protect a variety of equipment, such as motors, variable frequency drives, pumps, and fans.

• Building Electrical Systems: Used in the protection of building power distribution systems, ensuring safe and stable operation of electrical systems in commercial and residential buildings.

• Energy and Petrochemical Industries: Used in power protection in energy, oil, and chemical industries, ensuring stable operation of power facilities.

• Infrastructure Projects: Suitable for electrical protection systems in infrastructure projects like data centers and transportation facilities, ensuring the safety and long-term operation of equipment.

Precautions:

1. Proper Wiring: Ensure correct wiring according to the wiring diagram during installation to prevent malfunctions due to incorrect connections.

2. Regular Inspection: Periodically inspect the breaker’s operational status, particularly the overload and short circuit protection functions, ensuring they work properly to avoid failures.

3. Load Matching: Select the appropriate breaker model and rated current based on the actual load, avoiding frequent trips due to excessive load.

4. Environmental Suitability: Avoid exposing the breaker to high temperatures, humidity, or corrosive gases to extend its lifespan.

5. Safety Measures: Ensure the protection rating of the breaker matches the installation environment's requirements, and take additional protective measures when necessary.
