ABB 1SDA065523R1 Multi-voltage switch module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SDA065523R1 is a high-performance Multi-voltage Switch Module designed for industrial automation and power control systems, enabling switching and control of multi-voltage circuits. This module supports a wide input voltage range, features high dielectric strength, and fast response, suitable for safe control and load management in complex electrical systems. The 1SDA065523R1 has a compact design and high reliability, widely applicable in industrial control cabinets and automation equipment.

2. Technical Specifications

• Model: 1SDA065523R1

• Product Type: Multi-voltage Switch Module

• Input Voltage Range: 24–230 V AC/DC

• Output Current: 10 A

• Contact Type: SPST (Single Pole Single Throw) Normally Open

• Switching Frequency: Max 120 operations/minute

• Response Time: ≤ 20 ms

• Dielectric Strength: ≥ 2500 V

• Operating Temperature: -25 ℃ to +60 ℃

• Degree of Protection: IP20

• Mounting: DIN rail

• Certifications: CE, UL, IEC 60947-1/3

• Dimensions (Approx.): H 90 mm × W 45 mm × D 70 mm

3. Advantages & Features

1. Multi-voltage Compatibility
   Supports 24–230 V AC/DC input voltage for diverse industrial control systems.

2. High Dielectric Strength & Fast Response
   Dielectric strength ≥ 2500 V, response time ≤ 20 ms ensures fast and safe control.

3. Modular Design
   Compact structure facilitates integration into industrial control cabinets and automation equipment.

4. High Reliability
   Vibration-resistant, heat-tolerant, and long-term stable operation for industrial environments.

5. Easy Installation
   DIN rail mounting allows simple wiring and maintenance.

6. Safety Protection
   Built-in overload and short-circuit protection enhances equipment and operator safety.

4. Application Areas

The ABB 1SDA065523R1 Multi-voltage Switch Module is widely used in:

• Industrial automation control systems

• PLC and DCS control cabinets

• Power distribution and switching equipment

• Machinery manufacturing and production line control

• Water and wastewater treatment plant electrical control

• Building and municipal facility electrical management

5. Notes & Precautions

1. Ensure power is disconnected before installation to avoid electrical hazards.

2. Input voltage and output current must match load requirements to prevent module damage.

3. Install in a dry, ventilated environment, avoiding dust, moisture, and corrosive gases.

4. Regularly inspect terminals and wiring to ensure stable module operation.

5. Installation, commissioning, and maintenance should be performed by qualified electrical engineers.

6. Avoid long-term operation in strong electromagnetic interference environments; shielding may be required.
