ABB 1SDA062122R1 Rotary handle operating mechanism

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SDA062122R1 Rotary Handle Operating Mechanism is designed for low-voltage switches and circuit breakers, providing remote or local operation.
The mechanism is compact, safe, and reliable, capable of functioning in various installation orientations and environmental conditions, and is compatible with multiple ABB circuit breakers and isolators.

2. Main Technical Specifications (Typical)

• Model: 1SDA062122R1

• Product Type: Rotary Handle Operating Mechanism

• Applicable Devices: ABB low-voltage circuit breakers, isolators

• Operation Method: ON/OFF via rotary handle

• Mechanical Life: ≥ 5000 operations

• Locking Feature: Supports padlock to prevent misuse

• Mounting: Panel or external operation

• Mounting Dimensions: Standardized, compatible with ABB breaker panels

• Material: High-strength engineering plastic with metal core

• Operating Temperature Range: -25 ℃ to +60 ℃

• Protection Class: IP40 (when panel mounted)

3. Key Advantages and Features

1. Safe and Reliable Operation

   • Precise mechanical linkage, clear operation travel

   • Supports padlock to prevent unauthorized operation

2. Wide Applicability

   • Compatible with various ABB low-voltage circuit breakers and isolators

   • Supports multi-direction installation

3. High Durability

   • High-strength plastic and metal structure

   • Long mechanical life, ≥ 5000 operations

4. User-Friendly Operation

   • Ergonomic handle, smooth rotation

   • Supports remote or panel operation

5. Reliable Environmental Adaptability

   • Wide temperature range, suitable for industrial environments

   • Protection class meets standard low-voltage panel requirements

4. Typical Applications

• Operating low-voltage distribution circuit breakers

• Industrial automation control systems

• Power distribution in mining, petrochemical, and metallurgical plants

• Low-voltage electrical equipment in factories, buildings, and infrastructure

• Safety operation with padlock attachment

5. Installation and Maintenance Notes

1. Verify Compatibility

   • Ensure handle mechanism matches the circuit breaker model

2. Installation

   • Secure panel mounting

   • Confirm breaker status before rotating handle

3. Protection and Environment

   • Avoid moisture, corrosive and high-temperature environments

   • Keep handle and mechanism clean

4. Periodic Inspection

   • Check handle rotation smoothness

   • Verify padlock function reliability

5. Operational Precautions

   • Avoid excessive torque during operation

   • Do not forcibly operate under live conditions
