1. Product Overview

The ABB 1SDA060344R1 Switch Disconnector is a low-voltage isolating switch designed for ABB distribution systems. It safely disconnects circuits during maintenance or emergency conditions, protecting personnel and equipment. The switch provides clear ON/OFF status indication and can handle rated current loads. It can be combined with fuses or circuit breakers to form a complete circuit protection solution. It is suitable for industrial, commercial, and panel-mounted low-voltage power management systems.

2. Technical Specifications

• Model: 1SDA060344R1

• Product Type: Switch Disconnector

• Rated Voltage: AC 400 V / DC 250 V

• Rated Current: 32 A

• Poles: 3

• Breaking Capacity: Compliant with IEC 60947-3

• Mounting: Panel mount / DIN rail mount

• Operation: Handle operation with ON/OFF indication

• Mechanical Life: ≥ 10,000 operations

• Electrical Life: Compliant with industrial standards

• Degree of Protection: IP20

• Operating Temperature: –25 ℃ to +60 ℃

• Standards: IEC 60947-3 / CE

3. Advantages and Features

1. Safe and Reliable
   Clear ON/OFF indication ensures safe operation and effective circuit isolation.

2. High Load Capacity
   Supports rated current load and can withstand short-term overloads.

3. Standardized Installation
   Supports panel or DIN rail mounting for easy integration in industrial or building distribution panels.

4. Industrial-Grade Durability
   Long mechanical life and suitable for high-temperature, vibration, and industrial environments.

5. Compatible with Protective Devices
   Can be combined with fuses or circuit breakers for complete low-voltage circuit protection solutions.

4. Applications

• Industrial motors and distribution equipment

• Building low-voltage power distribution

• Distribution panels and switchboards

• Factory automation and control systems

• Power maintenance and safety isolation operations

5. Installation and Usage Notes

1. Verify rated voltage and current compatibility with the system before installation.

2. Ensure power is disconnected before installation or maintenance.

3. Correctly connect input and output wiring to ensure reliable contact.

4. Regularly inspect switch condition and handle integrity to prevent misoperation.

5. Avoid installation in high humidity, dust, or corrosive environments; provide protective measures if necessary.
