ABB 1SDA060268R1 molded case circuit breaker
Item NO.:
1SDA060268R1Payment:
T/TPrice:
$1000Product Origin:
SwedenColor:
NEWLead Time:
In stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB 1SDA060268R1 molded case circuit breaker (MCCB) is part of the Tmax T5 series, designed for protection and control of electrical distribution systems. It provides overload, short-circuit, and undervoltage protection with high breaking capacity and excellent mechanical endurance. Widely used in industrial, commercial, and infrastructure power systems, it ensures safe and reliable operation.
| Item | Specification |
|---|---|
| Model | 1SDA060268R1 |
| Series | Tmax T5 |
| Type | Molded Case Circuit Breaker (MCCB) |
| Rated Current (In) | 400 A |
| Rated Operational Voltage (Ue) | 690 VAC |
| Rated Insulation Voltage (Ui) | 800 VAC |
| Rated Impulse Withstand Voltage (Uimp) | 8 kV |
| Rated Short-Circuit Breaking Capacity (Icu) | 70 kA @ 415 VAC |
| Poles | 3P |
| Frequency | 50/60 Hz |
| Trip Unit Type | Thermal-magnetic or electronic trip unit |
| Mechanical Life | ≥ 20,000 operations |
| Electrical Life | ≥ 10,000 operations |
| Mounting Type | Fixed / Plug-in / Withdrawable |
| Protection Degree | IP40 (up to IP54 when mounted in an enclosure) |
| Operating Temperature | –25 °C to +70 °C |
| Standards | IEC 60947-2, EN 60947-2, GB 14048.2 |
High Breaking Capacity – Up to 70 kA breaking capability ensures reliable circuit protection.
Advanced Trip Unit Options – Thermal-magnetic or electronic trip units provide precise and adjustable protection.
Compact & Robust Design – Small footprint with high mechanical reliability and stable performance.
Flexible Installation – Available in fixed, plug-in, or withdrawable configurations.
Excellent Environmental Resistance – Operates reliably in harsh conditions such as heat, humidity, or dust.
International Compliance – Meets major global standards for safety and compatibility.
The ABB 1SDA060268R1 MCCB is widely used in:
Industrial power distribution systems
Commercial and residential building protection
Data centers and IT infrastructure
Energy and utility installations
Petrochemical and mining sectors
Renewable energy systems (solar, wind)
Machinery and control panel protection
The structure and details of the product：
