ABB 1SDA054866R1 shunt open release

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 1SDA054866R1 Shunt Open Release – Product Information

1. Product Overview

The ABB 1SDA054866R1 Shunt Open Release is an electrical accessory designed for ABB air circuit breakers (ACB) and molded case circuit breakers (MCCB).
It enables remote tripping of the circuit breaker when an external control signal or voltage is applied, providing remote control and system protection functionality. This device is widely used in power distribution, industrial automation, and energy management systems.

2. Technical Specifications

• Model: 1SDA054866R1

• Name: Shunt Open Release

• Brand: ABB

• Compatible Circuit Breakers: Emax 2 ACB / Tmax MCCB series

• Rated Voltage: 110 – 250 V AC / DC

• Operating Voltage Range: 70% – 110% of rated voltage

• Power Consumption: Approx. 10 W

• Operating Time: ≤ 30 ms

• Mounting Type: Modular plug-in installation

• Ambient Temperature: -25 ℃ to +70 ℃

• Protection Class: IP20

• Dielectric Strength: 2.5 kV

• Compliance Standards: IEC/EN 60947-2

3. Features and Advantages

1. Remote Tripping Capability – Enables remote control of breaker disconnection.

2. High Reliability – Fast response and stable operation with robust electromagnetic design.

3. Wide Voltage Compatibility – Suitable for both AC/DC 110–250V systems.

4. Easy Installation – Modular design for quick integration with ABB breakers.

5. Enhanced Safety – Electrically isolated and protected for safe operation.

6. Long Service Life – Durable coil design ensures stable performance over time.

7. Strong Compatibility – Seamlessly integrates with ABB ACB and MCCB product lines.

4. Application Areas

• Power distribution and protection systems

• Industrial automation and control

• Power plant and substation control panels

• Commercial and residential building power systems

• Data centers and communication facility power systems

• Energy management and remote control systems

5. Precautions

1. Ensure correct compatibility between the shunt release and the circuit breaker model.

2. Verify proper wiring polarity and voltage rating before connection.

3. Do not install or remove while the system is energized.

4. Periodically inspect the tripping mechanism to ensure proper functionality.

5. Avoid installation in humid, dusty, or high-interference environments.

6. Only qualified personnel should perform installation or maintenance.
