ABB 1SDA051236R1 Molded Case Circuit Breaker

• ABB 1SDA051236R1 Molded Case Circuit Breaker (MCCB)

  1. Product Overview

  The ABB 1SDA051236R1 is a high-performance Molded Case Circuit Breaker (MCCB) designed for industrial, commercial, and large building power systems. It provides protection against overload, short-circuit, and undervoltage conditions. The breaker features a thermal-magnetic trip unit with adjustable overload protection and high breaking capacity, ensuring safe and reliable operation of electrical systems.

  2. Technical Specifications

  • Model: 1SDA051236R1

  • Type: Molded Case Circuit Breaker (MCCB)

  • Poles: 3-pole

  • Rated Current: 100 A

  • Rated Operating Voltage: Up to 690 V AC / 500 V DC

  • Rated Insulation Voltage: 800 V

  • Ultimate Short-Circuit Breaking Capacity (I_cu):
    • 220–230 V AC ≈ 12 kA
    • 380–440 V AC ≈ 85 kA
    • 500 V AC ≈ 50 kA
    • 690 V AC ≈ 10 kA

  • Service Short-Circuit Breaking Capacity (I_cs):
    • 220–230 V AC ≈ 120 kA
    • 380–415 V AC ≈ 70 kA
    • 500 V AC ≈ 37.5 kA
    • 690 V AC ≈ 7.5 kA

  • Power Loss: ~8.5 W/pole

  • Mechanical Life: ~25,000 operations

  • Electrical Life: ~8,000 operations

  • Terminal Connection: Fixed front terminals

  • Mounting: Panel or DIN rail mounting

  • Protection Rating: IP20

  • Operating Temperature: -25 °C to +55 °C

  • Standards: IEC 60947 series

  3. Advantages and Features

  1. Comprehensive Protection: Prevents damage from overload, short-circuit, and undervoltage.

  2. High Breaking Capacity: Reliable short-circuit interruption across various voltages.

  3. Durable and Reliable: Thermal-magnetic trip ensures long mechanical and electrical life.

  4. Standard Compliance: IEC 60947 compliant for global compatibility.

  5. Compact Design: Modular and space-saving for high-density installation in distribution panels.

  4. Typical Applications

  • Industrial power distribution systems

  • Commercial and large building main distribution boards

  • Motor Control Centers (MCC)

  • Low-voltage distribution in substations

  • Equipment and load isolation protection

  5. Installation and Usage Notes

  • Disconnect power before installation to ensure safety.

  • Verify breaker rated current matches system load to avoid overload or nuisance tripping.

  • Follow wiring diagrams for correct connections.

  • Regularly inspect terminals, handles, and trip mechanisms.

  • Avoid long-term use in humid, corrosive, or high-vibration environments.

•

The structure and details of the product：
