ABB 1SDA013863R1 Connector Contact Auxiliary

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• 1. Product Overview

  The ABB 1SDA013863R1 is an auxiliary contact module designed to provide status signal output for main contactors or circuit breakers in low-voltage electrical control systems. It monitors the opening and closing status of main contacts, enabling remote signaling, interlocking, and signal acquisition for automation systems. Compact and easy to install, it is widely used in industrial and commercial distribution systems.

  ---

  2. Technical Specifications

  Parameter	Specification
  Model	1SDA013863R1
  Type	Auxiliary Contact Module / Connector Contact Auxiliary
  Contact Type	1 NO + 1 NC
  Rated Voltage	250 V AC / 30 V DC
  Rated Current	5 A
  Contact Resistance	≤ 50 mΩ
  Insulation Resistance	≥ 100 MΩ (500 V DC)
  Mechanical Life	≥ 1,000,000 operations
  Electrical Life	≥ 100,000 operations
  Mounting	Direct plug-in to main contactor or circuit breaker
  Operating Temperature	-25 ℃ ~ +55 ℃
  Protection Rating	IP20
  Standards	IEC/EN 60947-1 / IEC/EN 60947-5-1

  ---

  3. Key Features and Benefits

  • High reliability: Precise contacts ensure accurate signal output and main contact monitoring.

  • Easy installation: Directly plugs into main contactor or circuit breaker, no extra wiring required.

  • Compact design: Space-saving for control panel and distribution board installation.

  • Long service life: Mechanical life up to 1,000,000 operations, electrical life 100,000 operations.

  • Standards compliant: IEC/EN certified for safe industrial and commercial applications.

  ---

  4. Typical Applications

  • Status monitoring of circuit breakers and contactors in distribution systems

  • Signal acquisition in industrial automation control systems

  • Interface signal output to PLC control systems

  • Remote monitoring and alarm in power distribution

  • Auxiliary control in commercial and industrial distribution boards

  ---

  5. Installation & Usage Notes

  1. Compatibility: Only use with compatible ABB contactors or circuit breakers to ensure synchronized operation.

  2. Electrical connection: Ensure load voltage and current are within rated range to prevent contact damage.

  3. Environmental conditions: Avoid high temperature, humidity, and corrosive environments.

  4. Regular inspection: Check contact condition and mechanical operation periodically to ensure stable signal transmission.

•

The structure and details of the product：
