ABB 1SCA115448R1001 Fuse Disconnect Switch

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SCA115448R1001 Fuse Disconnect Switch is a key protective device in industrial low-voltage distribution systems, combining an isolator switch with a fuse for safe circuit disconnection, overcurrent protection, and maintenance isolation. It is manually operated, compact, and suitable for control cabinets, distribution panels, and industrial installations, providing reliable overload and short-circuit protection.

This model complies with IEC 60947-3 standards and features clear ON/OFF position indication for easy operation and maintenance. It supports various types of industrial fuses.

2. Technical Specifications

3. Key Features & Advantages

• Dual protection: Combines isolator switch and fuse for safe disconnection and overcurrent protection

• Reliable operation: Smooth manual operation with clear position indication

• High short-circuit withstand: Up to 50 kA rated short-circuit capacity for industrial high-load conditions

• Compact design: Space-saving, suitable for distribution cabinets and industrial installations

• Durable and reliable: Long mechanical life, corrosion-resistant and flame-retardant materials

• Flexible compatibility: Supports various NH series fuses for flexible selection

4. Typical Applications

• Industrial low-voltage distribution systems

• Power distribution and control cabinets

• Automated production lines

• Motor Control Centers (MCC)

• Chemical, pharmaceutical, paper, and metallurgical industries

• Overcurrent and short-circuit protection of industrial equipment

5. Installation & Safety Notes

1. Ensure rated voltage and current match the load requirements.

2. Select NH series fuses according to load current and protection needs.

3. Install in a ventilated, dry environment; avoid high temperature, humidity, or corrosive conditions.

4. Ensure load is disconnected before operating the switch to guarantee isolation safety.

5. Regularly inspect switch, fuse, and terminal conditions to prevent loosening or overheating.

6. Maintain panel cleanliness; prevent dust or foreign objects from affecting switch performance.

7. Follow IEC/EN standards strictly for safe and reliable installation and operation.

The structure and details of the product：
