ABB 1SBL407001R1300 magnetic contactor
Item NO.:
1SBL407001R1300Payment:
T/TPrice:
$1300Product Origin:
SwedenColor:
NEWProduct weight:
0.5KGLead Time:
in stockWe will arrange delivery within 3-5 days after receiving the payment.
Our express delivery: DHL and FedEx.
Quality packing for each product
Destination country all taxes & duty to be paid by buyer
Only part of the brand and model, if you have other product needs, please contact us.
The ABB 1SBL407001R1300 (model AF09-30-10-13) is a magnetic contactor designed for motor and load control applications.
It features AF electronic coil technology, enabling operation across a wide control voltage range (100–250 V AC/DC) and providing superior energy efficiency and reduced electromagnetic interference.
The contactor includes three main NO contacts and one auxiliary NO contact, suitable for switching AC-3 duty motors and general-purpose loads.
| Parameter | Specification |
|---|---|
| Model | 1SBL407001R1300 |
| Series | AF09-30-10-13 |
| Main Contacts | 3 NO |
| Auxiliary Contacts | 1 NO |
| Control Voltage | 100–250 V AC/DC (50/60 Hz universal) |
| Rated Operational Current (AC-3, 400 V) | 9 A |
| Rated Power (AC-3, 400 V) | 4 kW |
| Thermal Current (Ith) | 20 A at 40 °C |
| Rated Operational Voltage (Ue) | up to 690 V AC |
| Rated Insulation Voltage (Ui) | 690 V AC |
| Impulse Withstand Voltage (Uimp) | 6 kV |
| Coil Type | Electronic wide-range coil with surge suppression |
| Operating Frequency | Mechanical: 3000 ops/h; Electrical: 600 ops/h |
| Mechanical Life | 10 million operations |
| Electrical Life (AC-3) | 1 million operations |
| Protection Degree | IP20 (terminals and coil) |
| Mounting | 35 mm DIN rail or screw fixing |
| Ambient Temperature | –40 °C to +70 °C |
| Installation Position | Any orientation |
| Dimensions (W×H×D) | 45 mm × 80 mm × 86 mm |
| Weight | Approx. 0.33 kg |
Wide voltage coil (AF technology)
Operates from 100 to 250 V AC/DC without coil change — reducing stock and simplifying control design.
High reliability & low energy consumption
Built-in surge suppression and low-noise design ensure stable operation and low interference.
Extended mechanical and electrical life
Silver alloy contacts ensure long lifespan — up to 10 million mechanical operations.
Modular compatibility
Easily combined with ABB overload relays, auxiliary blocks, interlocks, or surge suppressors.
Easy installation & compact size
DIN rail mounting saves space; ideal for modern control panels.
Industrial durability
Designed to withstand harsh electrical environments, wide temperature tolerance, and vibration.
AC motor control (start / stop / reversing)
Pumps, fans, and compressor systems
HVAC and building automation
Heating and lighting control
Industrial automation and control cabinets
Auxiliary control in power distribution systems
Check control voltage
Ensure supply within 100–250 V AC/DC range; over- or under-voltage may affect performance.
Auxiliary contact usage
Use auxiliary contacts only for signal circuits, not for high-current loads.
Proper wiring
Use the correct cable size and tighten terminals firmly to avoid overheating.
Environmental conditions
Install in clean, dry environments; ensure proper ventilation and avoid corrosive gases.
Surge and interference protection
For inductive loads, additional suppression devices (RC or diode) are recommended.
Routine maintenance
Inspect contacts, insulation, and terminal tightness periodically.
Thermal overload relay pairing
Recommended to use with ABB TA25DU or TA42DU overload relays for complete motor protection.
The structure and details of the product：
