ABB 1SBL241024R8010 Three-pole contactor

1. Product Overview

The ABB 1SBL241024R8010 Three‑pole Contactor is a high‑performance AC electromagnetic contactor for low‑voltage applications.
It is designed to remotely switch AC loads such as motors, heaters, lighting, and other electrical equipment. It may be combined with thermal overload relays for motor protection. Known for reliable structure, rapid action, and easy installation, this contactor is widely used in industrial automation control systems.

2. Technical Specifications

• Model: 1SBL241024R8010

• Type: Three‑pole AC Contactor

• Brand: ABB

• Poles: 3 poles

• Rated Operational Voltage (Ue): AC 690 V

• Coil Voltage: AC 24 V (other coil voltages optional upon request)

• Rated Operational Current (Ie): 24 A (AC‑3 duty)

• Coil Frequency: 50/60 Hz

• Auxiliary Contacts: Optional auxiliary NO/NC modules

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 200,000 operations (at rated load)

• Mounting: Base or DIN rail mount (depending on accessory)

• Protection Class: IP20

• Insulation Class: Class F (enhanced thermal tolerance)

• Standards Compliance: IEC 60947‑4‑1 / EN 60947‑4‑1

• Operating Temperature: ‑25 ℃ to +55 ℃

3. Key Advantages & Features

1. High Reliability
   Industrial coil and silver alloy contacts provide long‑lasting, dependable performance.

2. Extended Lifespan
   Both mechanical and electrical lives are high, suitable for frequent switching operations.

3. Fast Operation
   Quick response improves control performance and system safety.

4. Modular Expandability
   Supports installation of auxiliary contacts, mechanical interlocks, and status indicators for complex control schemes.

5. Easy Installation & Maintenance
   Supports DIN rail or base mounting, adaptable to different installation layouts with simple field adjustment.

6. Wide Compatibility
   Works with overload relays, circuit breakers, PLCs and other protection/control devices.

4. Typical Applications

• Motor start/stop control in industrial equipment

• Automation line control systems

• Remote switching of heaters, lighting, and power loads

• Control of fans, pumps, compressors, and other drives

• Main or branch circuit control in control panels and distribution systems

• HVAC system control

5. Installation & Usage Notes

1. Rated Matching
   Ensure the contactor’s rated current matches the load to prevent overload damage.

2. Coil Voltage Matching
   Confirm the control supply voltage matches the coil rating to avoid coil burnout or malfunction.

3. Proper Wiring
   Wire main and control circuits according to wiring diagrams and tighten terminals securely.

4. Environmental Conditions
   Install in clean, dry environments free of corrosive gases; avoid high humidity or high temperatures that can degrade insulation.

5. Periodic Inspection
   Regularly inspect contact wear, electrical contact quality, and coil condition for long‑term reliable operation.

6. Interlock Configuration
   For complex systems, use auxiliary contacts and interlocks for enhanced operational safety.
