ABB 1SBL176501R2300 Contactor

Product Information: ABB 1SBL176501R2300 Contactor

Detailed Specifications:

• Model: 1SBL176501R2300

• Type: Contactor

• Rated Voltage: 24 V DC to 690 V AC

• Rated Current: 80 A

• Auxiliary Contacts: 2 NO + 2 NC

• Operating Frequency: 50/60 Hz

• Mounting Type: DIN rail mount

• Operating Temperature Range: -25°C to +55°C

• Dimensions: 105 x 45 x 122 mm

• Weight: 0.75 kg

• Ingress Protection: IP20

• Mechanical Life: 10,000,000 operations

• Electrical Life: 1,000,000 operations

• Certifications: CE, UL

Product Advantages and Features:

1. High Load Capacity: The ABB 1SBL176501R2300 contactor has a rated current of up to 80 A, making it suitable for controlling and protecting a wide range of industrial equipment with high load requirements.

2. Multiple Auxiliary Contacts: Equipped with 2 NO and 2 NC auxiliary contacts, providing more control and feedback options, offering flexibility to meet different application needs.

3. Long-Term Durability: With a mechanical life of 10,000,000 operations and an electrical life of 1,000,000 operations, this contactor can reliably operate for long periods in harsh industrial environments.

4. Wide Voltage Range: Supports a wide voltage range from 24 V DC to 690 V AC, making it suitable for global power systems and various control equipment.

5. Compact Design: The small size (105 x 45 x 122 mm) allows for easy installation in confined spaces, saving valuable equipment space.

6. High Reliability and Safety: Designed and manufactured with advanced materials to ensure stable and reliable performance over time, while meeting international safety standards.

Applications:

• Motor Control: Widely used in motor control systems to control motor start/stop operations and protect motors from overload and short circuits.

• Industrial Automation: Applied to control various industrial automation equipment, such as conveyors, pumps, fans, and other electrical devices.

• Power Distribution: Used in power distribution systems to control the switching and distribution of electrical power, ensuring stable system operation.

• HVAC Systems: Used in HVAC systems for controlling electrical power to equipment such as air conditioners, heating systems, and ventilation units.

• Building Facility Management: Used in building automation control systems to manage electrical facilities such as lighting, air conditioning, and other equipment.

Precautions:

1. Installation Requirements: During installation, ensure proper wiring according to electrical standards and make sure the contactor is installed in an environment that matches the specified operating temperature range.

2. Environmental Suitability: Avoid using the contactor in high humidity or corrosive gas environments to prevent equipment failure or shortened lifespan.

3. Regular Maintenance: Periodically inspect the contactor's contacts and electrical connections to ensure there are no issues with poor contact or aging, avoiding safety risks.

4. Load Management: Ensure that the load current does not exceed the rated value to prevent overload and damage to the contactor.

5. Protection Measures: Consider using external protective enclosures or seals when using the device in extreme environments to enhance its protection.
