1. Product Overview

The ABB 1SBL137001R1301 is a high-performance AC Contactor designed for electrical control systems to remotely switch motors, heaters, and other loads. It features high reliability, fast response, and strong arc resistance, suitable for frequent operation in industrial environments. The 1SBL137001R1301 includes standard auxiliary contacts for system signal acquisition and control, widely used in automated production lines, motor control, and factory electrical equipment.

2. Technical Specifications

• Model: 1SBL137001R1301

• Product Type: AC Contactor

• Rated Operating Voltage: AC 690 V

• Rated Current: 25 A

• Contact Configuration: 3 NO main contacts + 1 NO auxiliary contact

• Coil Control Voltage: AC 24 V / 48 V / 110 V / 230 V (optional)

• Mechanical Life: ≥ 10,000,000 operations

• Electrical Life: ≥ 300,000 operations (rated load)

• Operating Temperature: -25 ℃ to +60 ℃

• Storage Temperature: -40 ℃ to +85 ℃

• Degree of Protection: IP20

• Mounting: DIN rail or bolt-fixed

• Certifications: CE, UL, IEC 60947-4-1

• Dimensions (Approx.): H 85 mm × W 45 mm × D 75 mm

3. Advantages & Features

1. High Reliability & Durability
   Industrial-grade design supports frequent operation for long-term stable performance.

2. Fast Response & High Arc Resistance
   Electromagnetic operation suitable for motor start-up, load switching, and industrial control.

3. Multiple Contact Configuration
   3 NO main contacts + 1 NO auxiliary contact for control and signal feedback.

4. Modular Installation
   Supports DIN rail or bolt-fixed mounting for easy integration and maintenance.

5. Wide Temperature Adaptability
   Stable operation in -25 ℃ to +60 ℃ environments.

6. Comprehensive Certifications
   CE, UL, IEC 60947-4-1 certified, meeting global industrial application standards.

4. Application Areas

The ABB 1SBL137001R1301 Contactor is widely used in:

• Industrial automation control systems

• Motor start-up and protection

• Electric heater and lighting load control

• Factory equipment and production line automation

• HVAC systems and large machinery

• PLC output control

5. Notes & Precautions

1. Disconnect power before installation to ensure safety.

2. Coil control voltage must comply with specifications to prevent damage.

3. Main contact load current must be within rated limits to avoid overload.

4. Install in a dry, ventilated environment, avoiding dust, moisture, and corrosive gases.

5. Regularly inspect terminals and contacts to ensure reliable operation.

6. Installation, commissioning, and maintenance should be performed by qualified electrical engineers.
