ABB 1SBL136501R2300 Contactor

Product Information: ABB 1SBL136501R2300 Contactor

Detailed Specifications:

• Model: 1SBL136501R2300

• Type: Contactor

• Rated Voltage: 230 V AC

• Rated Current: 12 A

• Rated Power: 5.5 kW

• Contact Type: 1 Normally Open (NO) + 1 Normally Closed (NC)

• Operating Frequency: 50/60 Hz

• Control Voltage: 230 V AC

• Operating Temperature Range: -25°C to +60°C

• Ingress Protection: IP20

• Mounting Type: DIN rail mount

• Dimensions: 72 x 45 x 100 mm

• Weight: 0.3 kg

• Certifications: CE, UL

Product Advantages and Features:

1. High Reliability: The ABB 1SBL136501R2300 contactor is made with high-quality materials and precision engineering, providing reliable electrical control performance and ensuring stable operation of the equipment.

2. Multifunctional Design: Equipped with 1 NO and 1 NC contact types, it offers flexible control options and is suitable for various control and automation applications.

3. Wide Voltage Range: Designed for 230 V AC systems, it meets the requirements of various industrial automation control systems.

4. Compact Design: The compact size (72 x 45 x 100 mm) makes it easy to install in space-constrained environments and facilitates easy connection with other devices.

5. Efficient Power Control: With a rated power of 5.5 kW, it is ideal for controlling motors and high-power equipment, effectively managing the start/stop operations of loads.

6. High Temperature Adaptability: It operates stably within a temperature range of -25°C to +60°C, making it suitable for use in various harsh environments.

Applications:

• Motor Control: Widely used in motor control systems, especially for starting and stopping three-phase motors and high-power equipment such as pumps, fans, and compressors.

• Industrial Automation: Used in electrical control systems for industrial automation, particularly for controlling automation production lines and industrial equipment.

• Building Automation: Suitable for use in building automation systems for lighting and HVAC control, enabling power switching through contactors.

• HVAC Systems: Used in HVAC systems to control the operation of fans, cooling systems, and other electrical equipment, ensuring the normal operation of the system.

• Power Distribution Systems: Applied in power distribution systems to control the switching of electrical power, ensuring stable operation of the equipment.

Precautions:

1. Proper Installation: Ensure proper wiring and installation of the contactor according to the manual to ensure normal operation and avoid wiring errors.

2. Load Management: Ensure the load current and power do not exceed the rated values of the contactor to avoid damage or failure due to overloading.

3. Regular Inspection: Periodically inspect the contactor's contacts and electrical connections to ensure normal operation and prevent failures due to poor contact or aging.

4. Environmental Suitability: Avoid exposing the contactor to extreme temperatures, humidity, or corrosive environments to extend its lifespan.

5. Maintenance Advice: Regularly clean the contactor's housing to maintain optimal heat dissipation and protective performance, ensuring long-term stable operation.
