ABB 1SBH136001R2322 Contactor Relay

Product Information: ABB 1SBH136001R2322 Contactor Relay

Detailed Specifications:

• Model: 1SBH136001R2322

• Type: Contactor Relay

• Rated Voltage: 24 V DC to 240 V AC

• Rated Current: 10 A

• Contact Type: 1 NO + 1 NC

• Operating Frequency: 50/60 Hz

• Control Voltage: 24 V DC

• Rated Power: 2500 W (for small loads)

• Operating Temperature Range: -40°C to +60°C

• Mounting Type: DIN rail mount

• Ingress Protection: IP20

• Dimensions: 45 x 65 x 90 mm

• Weight: 0.25 kg

• Certifications: CE, UL

Product Advantages and Features:

1. High Reliability: The ABB 1SBH136001R2322 contactor relay is manufactured with high-quality materials and precision, providing reliable electrical control performance and ensuring stable operation.

2. Multifunctional Design: Equipped with 1 NO and 1 NC auxiliary contacts, this relay offers flexibility and versatility for various control and automation applications.

3. Wide Application Range: Suitable for a variety of operating voltages (24 V DC to 240 V AC), meeting the needs of different industrial automation systems.

4. Compact Design: Its compact size (45 x 65 x 90 mm) allows for installation in space-constrained environments, saving valuable equipment space.

5. Efficient Energy Control: With a rated power of up to 2500 W, it effectively controls small loads, making it ideal for precise energy management.

6. Strong Environmental Adaptability: It has a broad temperature range (-40°C to +60°C), making it suitable for use in various industrial and outdoor environments.

Applications:

• Industrial Automation: Widely used in industrial automation control systems for motor starting, controlling small devices' on/off operations, and more.

• Home Appliance Control: Used in home appliance systems for power control and automation switching, ensuring safety and energy-efficient operation.

• Lighting Systems: Applied in building automation for lighting control, allowing remote operation and control through relays.

• HVAC Systems: Used in HVAC systems to control fans, pumps, and other electrical equipment.

• Protection and Monitoring Systems: Used in electrical protection systems for fault detection and alarms, ensuring the safe operation of electrical devices.

Precautions:

1. Correct Installation: Ensure proper wiring and follow electrical safety standards during installation to guarantee the safety and stability of the device.

2. Avoid Overload: Ensure that the relay's load current does not exceed its rated value to prevent damage from overload.

3. Environmental Suitability: In environments with high humidity or corrosive gases, consider using external protective enclosures to prevent device damage.

4. Regular Inspection: Periodically check the relay's contacts and electrical connections to ensure proper functioning and avoid failures due to poor contact or aging.

5. Maintenance Advice: Regularly clean the relay housing to maintain optimal heat dissipation and protective performance.
