ABB 1SAX611001R1101 Electronic Overload Relay

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 1SAX611001R1101 Electronic Overload Relay is an intelligent relay module used for motor protection in ABB three-phase contactor and motor control systems. It monitors motor current in real time, providing overload, short-circuit, and phase-failure protection, with fast response and alarm functions to ensure safe operation of motors and systems.

2. Technical Specifications (Typical)

• Model: 1SAX611001R1101

• Type: Electronic Overload Relay

• Applicable Motor Rated Current: 0.1 A – 63 A (adjustable)

• Operating Voltage: AC 230–690 V

• Operating Frequency: 50/60 Hz

• Protection Functions: Overload, short-circuit, phase-failure protection

• Adjustment Method: Electronic adjustment with settable current range

• Response Time: Fast electronic response

• Interface: Directly mounts with ABB contactors

• Mounting: DIN rail or panel installation

• Operating Temperature: ‑25 °C to +60 °C

• Protection Class: IP20

• Indication: LED status and alarm display

3. Advantages & Features

• Precise overload protection: Monitors motor current electronically for accurate protection and prevents false trips.

• Fast response: Quickly disconnects power during overload or fault to protect motors.

• Wide adjustable range: Suitable for motors with different rated currents.

• Easy installation and maintenance: Modular design, directly compatible with ABB contactors for quick replacement.

• High reliability: Industrial-grade design, suitable for high temperature, vibration, and continuous operation.

4. Typical Applications

• Industrial motor and drive system protection

• Motor starters and control cabinets

• Fans, pumps, compressors, and conveyor systems

• Industrial automation production lines

• Motor protection in power distribution systems

5. Installation & Operation Notes

1. Current matching: Ensure the relay rated current is above the motor’s normal operating current.

2. Correct wiring: Connect input and output terminals according to the manual to prevent poor contact.

3. Environmental conditions: Avoid humidity, dust, and corrosive gases; ensure proper ventilation.

4. Periodic inspection: Check relay status indicators and alarm functions for long-term reliability.

5. Compatibility with contactors: Ensure relay matches the ABB three-pole contactor to guarantee safe disconnection.
